QC11Y-4x2500 hydraulic stainless steel small shearing machine
QC11Y-4x2500 hydraulic stainless steel small shearing machine
1.The QC11Y cnc metal sheet guillotine shearing machine is entirely welded and treated with fireplace tempering.
2.It adopts the hydraulic gearing and the energy accumulator for return stroke.
3.The rolling guide with three-point support facilitates to improve the cutting quality.
4.The rectangular balance comes with 4 usable balance angles and has a long service life.
5.The adjustment of blade angles complies with the indicator,fast and convenient.
6.A beam alignment device is configured,which also can adjust the stroke of upper tool post in stepless mode.
7.The fence-type safety protection device is adopted by the QC11Y/K hydraulic guillotine shearing machine.
8.The back gauge dimension and cutting times are available in digital display.
9.The cutting angle is adjustable.
10.The QC11Y adopt Estun E21 system.
11.The OC11K-NC cnc metal sheet guillotine shearing machine is equipped with Estun E200 control system.
12.The QC11K-CNC cnc metal sheet guillotine shearing machine is applicable for plate cutting due to its adoption of DELEM DAC310/DAC360 CNC control system by Netherlands.Its back gauge adopts imported ball screw and liner guideway.
| Shearing thickness | Shearing width | Number of stroke mm | Backgauge range mm | Shearing angler | Backgauge range mm | Motor power KW | |
| 6x2500 | 6 | 2500 | 16~35 | 20-600 | 30’-1°30 | 600 | 7.5 |
| 6x3200 | 6 | 3200 | 14~35 | 20-600 | 30’-1°30 | 600 | 7.5 |
| 6x4000 | 6 | 4000 | 10~30 | 20-600 | 30’-1°30 | 600 | 7.5 |
| 6x5000 | 6 | 5000 | 10~30 | 20-800 | 30’-1°30 | 800 | 11 |
| 6x6000 | 6 | 6000 | 8~25 | 20-800 | 30’-1°30 | 800 | 11 |
| 8x2500 | 8 | 2500 | 14~30 | 20-600 | 30’-1°30 | 600 | 11 |
| 8x3200 | 8 | 3200 | 12~30 | 20-600 | 30’-2° | 600 | 11 |
| 8x4000 | 8 | 4000 | 10~25 | 20-600 | 30’-2° | 600 | 11 |
| 8x5000 | 8 | 5000 | 10~25 | 20-800 | 30’-2° | 800 | 15 |
| 8x6000 | 8 | 6000 | 8~20 | 20-800 | 30’-2° | 800 | 15 |
| 12x2500 | 12 | 2500 | 12~25 | 20-800 | 30’-2° | 800 | 15 |
| 12x3200 | 12 | 3200 | 12~25 | 20-800 | 30’-2° | 800 | 15 |
| 12x4000 | 12 | 4000 | 8~20 | 20-800 | 30’-2° | 800 | 15 |
| 12x5000 | 12 | 5000 | 8~20 | 20-800 | 30’-2° | 800 | 22 |
| 12x6000 | 12 | 6000 | 6~20 | 20-1000 | 30’-2° | 1000 | 30 |
| 16x2500 | 12 | 2500 | 12~20 | 20-800 | 30’-1°30 | 800 | 22 |
| 16x3200 | 16 | 3200 | 12~20 | 20-800 | 30’-1°30 | 800 | 22 |
| 16x4000 | 16 | 4000 | 8~15 | 20-800 | 30’-1°30 | 800 | 22 |
| 16x5000 | 16 | 5000 | 8~15 | 20-1000 | 30’-1°30 | 1000 | 30 |
| 16x6000 | 16 | 6000 | 6~15 | 20-1000 | 30’-1°30 | 1000 | 37 |
| 20x2500 | 20 | 2500 | 10~20 | 20-800 | 30’-3° | 800 | 30 |
| 20x3200 | 20 | 3200 | 10~20 | 20-800 | 30’-3° | 800 | 30 |
