Help CenterSEC45 Section Rolling Machine/ Material Folder Machine/ Section Bender Machine
Related Products
-
SEC45 Section Bender Machine/ Section Rolling Machine/ Pipe Bender MachineUS$ 1 - 10,000MOQ: 1 Set -
SEC45 Section Rolling Machine/ Section Bender Machine/ Section Bending MachineUS$ 1 - 10,000MOQ: 1 Set
-
SEC45 Section Bending Folding Machine/ Aluminum Bending Machine/ Steel Bending MachineUS$ 1 - 10,000MOQ: 1 Set
-
CS315A Manual Metal Circular Sawing MachineUS$ 1 - 100,000MOQ: 1 Set
-
SEC16 Hydraulic Profile Bending MachineUS$ 100 - 9,999MOQ: 1 Set
Specifications
1. pipe rolling machine2. Section rolling machine
3. section bender machine
- 1. Technical data
- SEC45 Section rolling machine/ pipe rolling machine/ section bender machine
|
Type Parameter |
SEC45 |
||
Max bending resistance of section modulus Cm³ |
45 |
||
Rolling speed m/min |
5 |
||
Yield limit MPa |
≤245 |
||
Angle iron inturn |
Max section of angle iron |
100×100×16 |
|
Mini rolling dia: mm |
1500 |
||
Mini section of angle iron |
36×36×5 |
||
Mini rolling dia: mm |
600 |
||
Angle iron outrun |
Angle iron |
100×100×16 |
|
Mini rolling dia: mm |
1300 |
||
Mini section of angle iron |
36×36×3 |
||
Mini rolling dia: mm |
600 |
||
Channel Outrun |
Type |
20 |
|
Mini rolling dia: mm |
1000 |
||
Channel Inturn |
Type |
20 |
|
Mini rolling dia: mm |
1150 |
||
Steel flat |
Max section |
200×30 |
|
Mini rolling dia: mm |
900 |
||
Steel flat vertical |
Max section |
10×30 |
|
Mini rolling dia: mm |
1000 |
||
Dimension(L*W*H)m |
1.6×1.26×1.53 |
||
Note: This machine can meet the requirements of 30L soft stainless pipe. Mini diameter of rolling >2400mm while the thickness of pipe should larger than 8mm.
2.Major Elements
Serial |
Items |
Manufacturer |
Remarks |
1 |
Motor Y Series |
Nantong |
|
2 |
Hydraulic Motor |
Ningbo |
|
3 |
Gear Pump |
Ningbo |
|
4 |
Hydraulic Valve |
Taiwan |
|
5 |
Oil cylinder |
Nantong |
|
6 |
Electrics |
Schinder |
|
7 |
Light Encode |
Wuxi |
|
8 |
Bearing |
Wafangdian |
|
9 |
PLC |
Taiwan |
|
10 |
Sealing |
Valqua |
|
11 |
Moulds |
Self-make |
Material:42GrMo, HRC50-56 |
