Specifications
1. Section bender machine2. section rolling machine
3. pipe bender machine
- 1. Technical data
SEC45 Section bender machine/ section rolling machine/ pipe bender machine
Type Parameter | SEC45 | ||
Max bending resistance of section modulus Cm³ | 45 | ||
Rolling speed m/min | 5 | ||
Yield limit MPa | ≤245 | ||
Angle iron inturn | Max section of angle iron | 100×100×16 | |
Mini rolling dia: mm | 1500 | ||
Mini section of angle iron | 36×36×5 | ||
Mini rolling dia: mm | 600 | ||
Angle iron outrun | Angle iron | 100×100×16 | |
Mini rolling dia: mm | 1300 | ||
Mini section of angle iron | 36×36×3 | ||
Mini rolling dia: mm | 600 | ||
Channel Outrun | Type | 20 | |
Mini rolling dia: mm | 1000 | ||
Channel Inturn | Type | 20 | |
Mini rolling dia: mm | 1150 | ||
Steel flat | Max section | 200×30 | |
Mini rolling dia: mm | 900 | ||
Steel flat vertical | Max section | 10×30 | |
Mini rolling dia: mm | 1000 | ||
Dimension(L*W*H)m | 1.6×1.26×1.53 | ||
Note: This machine can meet the requirements of 30L soft stainless pipe. Mini diameter of rolling >2400mm while the thickness of pipe should larger than 8mm.
2.Major Elements
Serial | Items | Manufacturer | Remarks |
1 | Motor Y Series | Nantong |
|
2 | Hydraulic Motor | Ningbo |
|
3 | Gear Pump | Ningbo |
|
4 | Hydraulic Valve | Taiwan |
|
5 | Oil cylinder | Nantong |
|
6 | Electrics | Schinder |
|
7 | Light Encode | Wuxi |
|
8 | Bearing | Wafangdian |
|
9 | PLC | Taiwan |
|
10 | Sealing | Valqua |
|
11 | Moulds | Self-make | Material:42GrMo, HRC50-56 |
