Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Processing Machinery Parts > Home Appliance Nomarlly Opened Phenolic Bimetal Thermostat
Home Appliance Nomarlly Opened Phenolic Bimetal Thermostat
US$ 0.2 - 0.5
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
HW, LC
Model Number:
4B-HR1
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Keelung
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1/2 Disc Type Temperature Controller ThermostatUS$ 0.2 - 0.8MOQ: 1000 Pieces -
16A 250V Home Appliance Bimetallic ThermostatUS$ 0.25 - 0.8MOQ: 1000 Pieces
-
Snap Action 16A Bimetal Type ThermostatUS$ 0.3 - 1MOQ: 1000 Pieces
-
T24-4A-BF2 Bimetallic Snap Action ThermostatUS$ 0.2 - 0.8MOQ: 1000 Units
-
Overheating Protection Bimetal ThermostatUS$ 0.2 - 1MOQ: 1000 Units
Place of Origin
Taiwan, China
Brand Name
HW, LC
Model Number
4B-HR1
Home Appliance Nomarlly Opened Phenolic Bimetal Thermostat
Overview:
(1) CONTACT TYPE : Contact Opens When Temperature Rises To Set Point (Normally Open)
(2) BRACKET TYPE : Brass hex stud mounting
(3) TERMINAL ORIENTATION :Vertical
(4) TERMINAL SIZE: Amp#187 TAB ( 4.75mm x 0.8t mm )
Specification:
| Electrical Rating | 16A/250V AC 15A/125V AC 10A/250V AC |
| Operation Temp |
40℃~200(ENEC) 40℃~205℃(UL/CUL) |
| Differential | 10K~65K |
| Calibration Method | 1℃/min. Air circulation furnace |
| Temp. Tolerance | ±3K / ±5K |
| Heat Durability | 180℃*2Hr MAX. |
| Circuit Resistance | 50 mΩ MAX. |
| Insulation Resistance | 100MΩ min. at DC 500V |
| Dielectric Strength |
AC1000V for One Minute or AC 1800V for One Second(Leak current:0.5mA) |
| Operation life |
100,000 Cycles(15A 125V AC / 10A 250V AC) 10,000 Cycles(16A 250V AC) |
