T24 Microwave Oven Bimetallic Thermostat
Overview:
(1) CONTACT TYPE : Contact Opens When Temperature Rises To Set Point (Normally Closed)
(2) BRACKET TYPE : Fixing Bracket
(3) TERMINAL ORIENTATION : Horizontal
(4) TERMINAL SIZE: Amp#187 TAB ( 4.8mm x 0.5tmm )
(5) HOUSING HEIGHT: 12.4mm
(6) MOUNTING HOLES: 24mm
Tolerance:
| Grade | A | B |
| Action ±°c | 3 | 5 |
| Action ±°c | 4 | 8 |
Specification:
Reset Type |
Automatic or Manual |
Contact Type on Rise |
NC |
Electrical Rating |
16A/250VAC 15A/125VAC 10A/250VAC |
Calibration Method |
1°C/min, Air circulation furnace |
|
Operating Temp. *
|
40°C~ 200°C (ENEC) 40°C~ 205°C (UL/CUL) |
Differential |
10K ~ 65K |
Temp. Tolerance |
±3K/ ±5K |
Heat Durability |
180°C * 2Hr Max. |
Circuit Resistance |
50 MΩ Max. |
Insulation Resistance |
100MΩ at DC 500V |
Dielectric Strength |
AC 1000V/min or AC 1800/sec (Leak Current 0.5mA) |
Operating Life |
100,000 Cycles (15A/125VAC, 10A/ 250VAC) 10,000 Cycles (16A/250VAC) |
* Action temp. and reset temp. can be set up depend on customer’s request
