T24-4A-RF2-A Bimetal Thermostat
US$ 0.2 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Brand Name:
HW
Model Number:
4A-RF2-A
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Water Dispenser Temperature Regulator Bimetal ThermostatUS$ 0.25 - 0.8MOQ: 1000 Pieces -
T24 15A 250V Home Appliance Bimetal ThermostatUS$ 0.2 - 0.6MOQ: 1000 Pieces
-
Washing Machine Bimetal Thermal Switch ThermostatUS$ 0.25 - 1MOQ: 1000 Pieces
-
16A Storage Heater Bimetal ThermostatUS$ 0.25 - 1MOQ: 1000 Pieces
-
T23-3M-RF2 Manual Reset Thermal Switch Bimetal ThermostatUS$ 0.2 - 1MOQ: 1000 Pieces
Brand Name
HW
Model Number
4A-RF2-A
T24-4A-RF2-A Bimetal Thermostat
Overview:
(1) CONTACT TYPE : Contact Opens When Temperature Rises To Set Point (Normally Closed)
(2) BRACKET TYPE : Alu. round stud mounting
(3) TERMINAL ORIENTATION : Horizontal
(4) TERMINAL SIZE: Amp#250 TAB ( 6.35mm x 0.8t mm )
Specification:
| Electrical Rating | 16A/250V AC 15A/125V AC 10A/250V AC |
| Operation Temp | 40℃~200(ENEC) ; 40℃~205℃(UL/CUL) |
| Differential | 10K~65K |
| Calibration Method | 1℃/min. Air circulation furnace |
| Temp. Tolerance | ±3K / ±5K |
| Heat Durability | 180℃*2Hr MAX. |
| Circuit Resistance | 50 mΩ MAX. |
| Insulation Resistance | 100MΩ min. at DC 500V |
| Dielectric Strength | AC1000V for One Minute or AC 1800V for One Second (Leak current:0.5mA) |
| Operation life | 100,000 Cycles(15A 125V AC / 10A 250V AC) ;10,000 Cycles(16A 250V AC) |
