Manual Reset Button 10A Bimetallic Thermostat
US$ 0.25 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
HW, LC
Model Number:
4M-DF2
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
T24-4A-XF1 Bimetal Thermostatic Switch ThermostatUS$ 0.2 - 0.8MOQ: 1000 Units -
4T-CF2 Twin Snap Action Bimetal ThermostatNegotiableMOQ: 1000 Pieces
-
T24 High Sensitivity Open Cap Bimetal ThermostatUS$ 0.2 - 0.5MOQ: 1000 Pieces
-
Snap Action Bimetal ThermostatUS$ 0.25 - 1MOQ: 1000 Pieces
-
T24-4A-RF2-A Bimetal ThermostatUS$ 0.2 - 1MOQ: 1000 Pieces
Place of Origin
Taiwan, China
Brand Name
HW, LC
Model Number
4M-DF2
Manual Reset Button Heater and Home Appliance Bimetallic Thermostat
Overview:
(1) CONTACT TYPE : Contact Opens When Temperature Rises To Set Point (Normally Closed)
(2) CAP TYPE : D Cap ( Stainless Steel )
(3) TERMINAL ORIENTATION : Horizontal
(4) TERMINAL SIZE: Amp#250 TAB ( 6.35mm x 0.8t mm )
(5) Manual Reset
Specification:
Reset Type |
Manual |
Contact Type on Rise |
NC |
Electrical Rating |
15A/125VAC |
Calibration Method |
1°C/min, Air circulation furnace |
Operating Temp. * |
40°C~ 205°C (UL/CUL) |
Differential |
10K ~ 65K |
Temp. Tolerance |
±3K/ ±5K |
Heat Durability |
180°C * 2Hr Max. |
Circuit Resistance |
50 MΩ Max. |
Insulation Resistance |
100MΩ at DC 500V |
Dielectric Strength |
AC 1000V/min or AC 1800/sec (Leak Current 0.5mA) |
Operating Life |
6,000 times |
* Action temp. and reset temp. can be set up depend on customer’s request
