Help CenterLS Series Pushbutton Switch
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
HW
Model Number:
LS
Payment & Shipping
Payment Methods:
Port of Shipment:
Taiwan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SS22F15 2P2T Vertical Type Slide SwitchUS$ 0.05 - 0.1MOQ: 2000 Pieces -
SS22F06 2P2T Vertical Type Slide SwitchNegotiableMOQ: 2000 Pieces
-
1P2T Horizontal Type Slide SwitchUS$ 0.05 - 0.1MOQ: 2000 Pieces
-
SK13D10 1P3T Horizontal Type Slide SwitchUS$ 0.05 - 0.1MOQ: 2000 Pieces
-
SS22H06 2 Pole 2 Throw Vertical Type Slide SwitchUS$ 0.05 - 0.1MOQ: 2000 Pieces
Place of Origin
Taiwan, China
Brand Name
HW
Model Number
LS
Mechanical Life
10,000
LS Series Pushbutton Switch
Application:
Computer, Office Appliances, Communication Equipments
LED Color:
Blue, Green, Red, Yellow
Switch Specification
| Pole Positioning | Momentary Type, Lock Type with LED |
| Contact Rating | 36VDC, 0.2A |
| Contact Resistance | 40mΩ max. 1.5VDC; 100mA by method of Voltage Drop. |
| Insulation Resistance | 100MΩ, 500VDC |
| Dielectric Strength | Breakdown is not allowable; 500 VAC for 1 min |
| Operating Force | 200 ± 100 gf |
| Operating Life | 10,000 cycles |
| Operating Temperature Range | -20°C ~ 70°C |
| Total Travel |
Full Travel: 22 ± 0.3mm Contact Travel: 1.6 ± 0.3mm |
