Specifications
1.low noise2.simple structure
3.rigid transfer clutch
EMM23-10 C-frame Inclinable Power Press machine
Features:
This series of button presses using rigid transfer clutch, simple structure, easy maintenance, the use of helical gears, smooth, the impact of small, low noise.
Championship glory, different.
Supreme heavyweight champion from the second forging press technology standards. There is no doubt that alone to give a series of press EMM23 sufficient strength, stability and lasting quality of life. Fifty years of manufacturing history, exercise an undisputed champion of stamping.
Technical Data:
Item |
Unit |
EMM23-10 |
|
Nominal pressure on sliding block(Pe) |
KN |
100 |
|
Nominal pressure stroke(Sp) |
mm |
2 |
|
Slide stroke(S) |
mm |
45 |
|
Stroke frequency |
Fast speed |
times/ |
145 |
Low speed |
|
||
Die height(H2) |
mm |
180 |
|
Die Height Adjustment(t) |
mm |
35 |
|
Distance between slider center and machine(C1) |
mm |
130 |
|
Vertical columns distance(d1) |
mm |
180 |
|
Slider bottom size |
L×R(a) |
mm |
170 |
F×B(b) |
mm |
150 |
|
Size of handle hole |
Diameter(d) |
mm |
30 |
Depth(I) |
mm |
55 |
|
Size of worktable |
L×R(C) |
mm |
370 |
F×B(D) |
mm |
240 |
|
Blanking hole diameter(Φ) |
mm |
80 |
|
Thickness of worktable(H3) |
mm |
35 |
|
Max. inclination angle |
Deg |
35 |
|
Worktable height(H1) |
mm |
730 |
|
Overall size |
L×R(A) |
mm |
900 |
F×B(B) |
mm |
665 |
|
Height(H) |
mm |
1658 |
|
Anchor bolts distance |
L×R(a’) |
mm |
610 |
F×B(b’) |
mm |
394 |
|
Power of electric motor |
kw |
1.1 |
|
Weight(Approximate) |
kg |
576 |
|
Main Parts List
Order |
Name |
Manufacturer |
Origin |
1 |
AC contactor, intermediate contactors |
Schneider |
France (buy from Shanghai Agent) |
2 |
Thermal relay, auxiliary connector |
Schneider |
France (buy from Shanghai Agent) |
3 |
Control buttons |
Schneider |
France (buy from Shanghai Agent) |
4 |
Motor |
Hua Li |
Shandong |
Wan Nan motor factory |
Anhui |
||
5 |
Two Hands button |
Izumi |
Japan (Buy from Shanghai Agent) |
6 |
Cylinder(Above 80T) |
Hong JU |
Dan yang |
7 |
Foot Switch |
Hong Ju |
Dan yang |
8 |
High pressure tubing(Above 80T) |
Ao kang |
Germany Base in Shanghai |
9 |
Air switch(Above 80T) |
Feidiao |
Shanghai |
10 |
Speed regulating Motor(Optional) |
Nai te |
Nanjing |
