EB63 hand operated pipe bending machine
- 100 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- 10mm hot press brake bending machine for brake pad
- Custom bending press brake and shearing machine
- Square steel tube press brake machine for making gutters
- CNC hydraulic press brake steel bar cutting and bending machine
- Crank type bending machine heavy duty press brake 125t 3200
- 6 axes cnc press brake machine hydraulic for making gutters ceramic
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | EMM |
Model Number: | EB63 | Machine Type: | Beading Machine | Raw Material: | Pipe |
Material / Metal Processed: | Stainless Steel | Power: | Hydraulic | Automation: | Automatic |
Extra Services: | Machining | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
EB63 hand operated pipe bending machine
Model | EB63 | Remark | |
Max bending capability | Φ63mm×4mm | 1. The Minimum bending diameter based on the pipe diameter 2.The Max bending diameter can according to the customer’s requirement 3.The Max length of mandrel can according to customer’s requirement | |
Max bending radius | R250mm | ||
Min bending radius | R30mm | ||
Max bending angle | 190° | ||
Max feeding length | 2850mm | ||
Working speed | Bending speed | Max 30°/s | |
Rotary speed | Max 160°/s | ||
Feeding speed | Max 800mm/s | ||
Working accuracy | Bending accuracy | ±0.15° | |
Rotary accuracy | ±0.15° | ||
Feeding accuracy | ±1mm | ||
Bending method | Hydraulic bending | ||
Power of rotary servo motor | 1.5kw | ||
Max bending groups | 12 | ||
Max storing components | 330 | ||
Motor power | 11kw | ||
Oil pressure | 12 Mpa | ||
Size | 5090 x 1350 x 1230mm | ||
Weight | 5500kg |
