EMMCHINA EM100 high precision manual bender for pipe
EMMCHINA EM100 high precision manual bender for pipe
Machine characteristics:
High performance middle size pipe bending machine, NC control, multi-groups program and multi angles setting, makes your operation and setting convenient. Widely used in mass production and standard products, such as: blast pipe, seat, fender guard, and all the steel furniture.
Technical Specification and Capacity
Specification/Model |
Unit |
EM38 |
EM50 |
EM63 |
EM75 |
EM89 |
EM100 |
Max bending capability |
mm |
Φ38*2 |
Φ50*3 |
Φ63*4 |
Φ75*4 |
Φ89*8 |
Φ100*8 |
Max bending radius |
mm |
R260 |
R350 |
R350 |
R400 |
R450 |
R500 |
Min bending radius |
mm |
According to the pipe diameter |
According to the pipe diameter |
According to the pipe diameter |
According to the pipe diameter |
According to the pipe diameter |
According to the pipe diameter |
Max bending angle |
degree |
190 |
|||||
Max effective distance of mandrel |
mm |
1600 |
2200 |
2600 |
2800 |
3500 |
3600 |
Control System |
NC Control |
||||||
Max elbow bend pipe |
unit |
16 |
|||||
Max storable sections |
unit |
16*16 |
|||||
Motor power |
kw |
4 |
5.5 |
5.5 |
7.5 |
11 |
15 |
Max. Hydraulic Pressure |
mpa |
12 |
12 |
12 |
12 |
14 |
14 |
Hydraulic System Control |
Electromagnetic Valve |
||||||
Oil Tank Capacity |
L |
110 |
150 |
220 |
250 |
260 |
300 |
Measurement |
mm |
2600*600*1000 |
3000*700*1030 |
3500*750*1100 |
4000*1000*1100 |
4550*1300*1300 |
5000*1600*1200 |
Weight of Machine |
kg |
750 |
1220 |
1500 |
2000 |
3500 |
5000 |
EMMCHINA EM100 high precision manual bender for pipe
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
EMMCHINA EM100 high precision manual bender for pipe
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
