4021industrial RO membrane for RO system
Specification
Active Area, 36(3.4) Ft2 (m2)
Removal rate, 99.5%
Water production rate, 1000GPD
Testing pressure, 150PSI
Test temperature, 25℃
Packing detail, 1PCS/CTN
Packing size, 57*12*12cm
Gross weight, 2.5KGS
Test conditions
1. The test is under water temperature 25°C, nacl 500mg /l, pH 7.5 and the standard recycle rate and so pressure.
2. The water output deviation of single membrane is between 15percent .of mean values.
3. The lowest desalination rate is 95.0%
Limited conditions
Max operation pressure ……………………………..600psi (4.2mpa)
Max feed water temperature …………………………45°C
Max feed water sdi …………………………………5
Max free chlorine in feed in water …………………less than 0.1mg /L
Range of feed water PH value of constant run …………..3to10
Range of feed water pH value of chemical cleaning …….2to 11
Max pressure drop of single out membrane ……………..15(0.1mpa)
| Model | Active Area | Removal rate | Water production rate | Test Pressure | Test temperature | Packing detail | |||
| Ft2 (m2) | % | GPD | Psi | ℃ | N.W (Kg/CTN) | G.W (Kg/CTN) | Qty/CTN | Packing size (cm) |
|
| LP/BW3020 | 26(2.4) | 99.5 | 600 | 150 | 25 | 1.4 | 1.6 | 1 | 57*12*12 |
| LP/BW4021 | 36(3.4) | 99.5 | 1000 | 150 | 25 | 2.1 | 2.5 | 1 | 57*12*12 |
| LP/BW4040 | 85(7.9) | 99.5 | 2200 | 150 | 25 | 3.6 | 4.3 | 1 | 110*12*12 |
| LP/BW8040 | 365(33.9) | 99.5 | 11040 | 150 | 25 | 14 | 15 | 1 | 110*24*24 |
