Specifications
1. long life2.low noise.
3.high rigidity and precision
CH1402J Big Bore cutting machine for metal /cnc lathe machine/cnc turning machine
Features:
1-This machine is a CNC lathe controlled by a microcomputer and driven by step motors. It is suitable for turning cylindrical and taper faces, boring, grooving and cutting threads (including taper threads).
2-The machine adopts ISO International Code, Keyboard Manual Date input, and it is also provided with program of power cut-off protection and the functions of automatic diagnosis and with RS232 interface.
3-Longitudinal and cross feeds are effected by ball leadscrews driven by servo motors.
Either vertical or horizontal 4 station or 6 station tool post or gang tools can be selected. The post is located on precision contrate gears with a high repeated positioning accuracy.
Hydraulic chuck, manual chuck, manual tailstock and hydraulic tailstock are available for your choice.
4-Infinitely variable speed change for spindle. The spindle bore is 80mm.The spindle system is high in the rigidity and accuracy.
Main specification
Item |
Unit |
CH1402J |
Max. swing over bed |
mm |
φ400 |
Max. swing over carriage |
mm |
φ210/φ165(for dang tools) |
Max. work piece length |
mm |
750 |
Max. turning length |
mm |
620 |
Spindle nose |
|
D8 |
Spindle bore |
mm |
φ80 |
Cone hole diameter and taper |
|
MT NO.7 |
Range of spindle speed |
r/min |
38-1680 |
Steps of spindle speed(Manual) |
|
12 |
Rapid feed for Longitudinal |
m/min |
10 |
Rapid feed for cross |
m/min |
8 |
Max. travel of Longitudinal |
mm |
710 |
Max. travel of cross |
mm |
250/330 |
Min. input |
mm |
0.001 |
Tool post stations |
|
4ways or 6ways or gang tools |
Tool cross section |
mm |
25*25 |
External diameter |
mm |
φ75 |
Taper of bore |
|
MT NO.4 |
Max. Traverse |
mm |
95 |
X/Z motor torque |
nm |
4.7/7 |
Main motor power |
kw |
5.5 |
Cooling pump power |
w |
75 |
Overall dimensions(L*W*H) |
mm |
2060*1150*1450 |
Net weight |
kg |
2250 |
