EMMCHINA SK332 horizontal lathe machine metal
EMMCHINA SK332 horizontal lathe machine metal is mainly used to process inside and outside the pipe thread as well as metric, inch thread. At the same time can also be used as a general ordinary lathe, for shaft, disk cylindrical parts, in the hole and face processing.
Machine is equipped with taper gear, can be used for processing parts with taper.
| Main features | Processed pipe thread diameter range | 190-320 mm |
| Max.swing over bed | 1000mm | |
| Max. swing over tool | 610mm | |
| piece length | 1700mm | |
| Windth of bed | 755mm | |
| Main Drive System | Spindle bore | 330mm |
| Steps of spindle speed | 9 | |
| Range of spindle speed | 7.5-280r/min | |
| Feed system | Feeding and thread pitch range | 0.0001-40mm |
| tool post transverse travel | 500mm | |
| Bed saddle longitudinal max. stroke | 1450 | |
| tool post | main shaft center to the vertical distance tool installation datum | 48mm |
| Cutting tools section size | 45x45mm | |
| Tailstock | Dia of sleeve | 140mm |
| Taper of sleeve | Morse 6 | |
| Sleeve stroke | 300 mm | |
| Lateral movement range | ±25mm | |
| Power system | Main motor | Y180L-4-B3 22KW 1460r/min |
| gear pump | CB-B10 2.5MPa 1450 r/min | |
| Main motor belt | 5-C2070 | |
| Gear pump belt | 1-A1270 | |
| Cooling system | Cooling pumps | JCB-45 0.15KW 22L/min |
| Machine | Overall dimensions(L*W*H) | 5000×2100×1600mm |
| Weight | 11000kg |
EMMCHINA SK332 horizontal lathe machine metal
Provide Pre-sales Consultant & On-purchase service 8 hr × 6 days per week
1. Reply within 24 hours
2. Provide relevant product information
3. Answer question of customer's requirement
4. Give technical suggestion
Provide After-sales service 24hr × 7days per week
1. Test the machine before shipment
2. Provide technical guidance relate to use the machine
3. Supply one-year warranty period for the machine
4. Provide the spare parts at cost price after warranty period
5. Collect the feedback for the machine working
6. Provide long-term technical assistance.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
EMMCHINA SK332 horizontal lathe machine metal
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
EMMCHINA SK332 horizontal lathe machine metal
