CW62160 horizontal gap bed lathe machine
The surface of the bedways is supersonic frequency handened. The spindle system is high in rigitidy and accuracy. Rapid feed structure is available on Apron. Clutch in headstock makes the lathe start.
| ITEMS | CW61140 /CW62140 | CW61160/ CW62160 |
| Max. swing over bed | Ø1400 mm | Ø1600 mm |
| Max. swing over carriage | Ø1060 mm | Ø1260 mm |
| *Over gap | Ø1930 mm | Ø2110 mm |
| Width of bed | 970 mm | |
| *Effective length of gap | 590 mm | |
| Max. length of work piece(two centers) | 1.5m/2m/3m/4m/5m/6m/8m/10m/12m | |
| Max. turning length | 1.3/1.8/2.8/3.8/4.8/5.8/7.8/9.8/11.8m | |
| Max. Weight of work piece(between centers) | 6000Kg | |
| Spindle nose | A2-15 | |
| Spindle bore | Ø130 | |
| Cone hole diameter and taper of spindle hole | Metric Ø140 1:20 | |
| Number of speeds | 24(normal),12(reverse) | |
| Spindle speed scope | 2.5~250rpm | |
| Pitch of longitudinal ball screw/diameter | 12 mm/ Ø70 | |
| Number of cross feeds | 97 | |
| Feed range of tool post for per rev. of spindle(Longitudinal) | 0.1~12 mm/r | |
| Feed range of tool post for per rev. of spindle(Cross) | 0.05~6 mm/r | |
| Feed range of tool post for per rev. of spindle(middle tool post) | 0.025~3 mm/r | |
| Rapid feed for Axis Z | 3740 mm/min | |
| Rapid feed for Axis X | 1870 mm/min | |
| Rapid feed for Axis middle tool post | 935 mm/min | |
| Thread cutting for Metric pitch threads(range/no.) | 1~120 mm/45 | |
| Thread cutting for Whit-worth pitch threads(range/no.) | 30~1/4 TPI/42 | |
| Thread cutting for Module threads(range/no.) | 0.5~60 mm/64 | |
| Thread cutting for D.P. threads(range/no.) | 1/2~60DP/48 | |
| Vertical distance from spindle center to installing basis | 51 mm | |
| Size of tool shank | 50×50 mm | |
| Max. travel of cross slide | 840mm | 900mm |
| Swing angle of tool post | ±90° | |
| Max. travel of middle tool post | 400 mm | |
| Max. travel of top slide | 200 mm | |
| Tailstock taper of bore | Metric 80 | |
| Tailstock sleeve travel | 300 mm | |
| Tailstock sleeve dia. | Ø160 mm | |
| Power of main motor | 22 KW | |
| Rapid feed motor power | 1.5 KW | |
| Power of cooling pump | 0.15 KW | |
| 3m Overall dimensions(L×W×H) | 6100×2080×2130mm | 6100×2130×2300mm |
| Net weight(3m) | 14100Kg | 15100Kg |
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
CW62160 horizontal gap bed lathe machine
