Q35Y-20 cnc sheet metal cutting machine
- 50 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Hydraulic Guillotine Type Metal Shear Used in Scrap Metal Recycling Industry
- Best price cnc table plasma cutting machine with water table
- High-power cnc plasma cutting machine 1530
- REBOUND CNC table plasma cutting machine for metal 1.5x3m
- REBOUND CNC new automatic plasma cutting machine with good price
- table cnc best price modern plasma cutting machine for stainless
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | EMM |
Model Number: | Q35Y-20 | Voltage: | 220V/380V/50HZ | Rated Power: | 4KW |
Dimension(L*W*H): | 1640*710*1780mm | Weight: | 1800kg | Certification: | ISO9001 |
Warranty: | 1 YEAR | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Q35Y-20 cnc sheet metal cutting machine1.easy maintenance
2.light weight
3.gain time
4.improve work efficiency
Q35Y-20 cnc sheet metal cutting machine
Q35Y-20 cnc sheet metal cutting machine is a machine tool integrating sheet metal cutting, punching, plate shearing, bending and other functions. Having the virtues of easy operation, low consumption and low maintenance cost, it is designed via the latest technology and with laser positioning function to better cater for market demands. Besides, it is configured with automatic press device and temperate control radiator, and has become the first choice for metal processing of modern manufacturing industries(such as the metallurgy, bridge, communication, electric power, military and other industries).
The double cylinder hydraulic ironworker enables shearing, punching and die cutting of plates and square, round ,U,angle and I steel as well as various structural steel materials. It is the first choice for mass processing of structural steel materials,and capable of bending the plates with the length of less than 500mm.The punching part is designed with a protective cover and the automatic stop gauge is mounted onto the machine back.We promise that all the components are provided in line with the highest quality requirements in safety,function,maintenance and performance aspects.
Product specification
Q35Y-20 cnc sheet metal cutting machine
Specification | Q35Y-16 | Q35Y-20 |
Punching station |
|
|
Punching maximum capacity | 25x16 | 30x20 |
Stroke Ram length | 80 | 80 |
Deep Throat Standard | 300 | 355 |
Punching Largest hole (Optional) | 160 | 160 |
Working height | 1030 | 1084 |
Shearing |
|
|
Flat Plate Shearing Maximum | 250x16 | 330x20 |
Flat Plate Shearing Maximum | 400x8 | 480x10 |
Blade length | 410 | 485 |
Angle Flange Trim Maximum 45° | 100x10 | 100x13 |
Working Height | 890 | 894 |
Angle Cutting Station |
|
|
90° Miter (True Interior /Exterior ) | 125x12 | 140x14 |
45° Miter (True Interior /Exterior ) | 70x10 | 70x10 |
Working Height | 1130 | 1180 |
Packing: Steel Pallet and waterproof cloth
Shipping: FOB shanghai by sea
1 year quality guaranty for the main spare parts, not include quick-wears parts, like blade, punch, die and so on.
During the guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us.
If the malfunctions are caused by customer's incorrect operations, we will offer the spare parts at cost price.
Anyway, our company promises to supply the customer cost price of spare parts and provide long-term technical guide beyond the guarantee.
EMM is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world.
EMMteam memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
Payment term
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
Delivery term
EX-WORS, FOB, CIF, CFR and so on
45 working days after receiving the deposit or original L/C.
