Specifications
1. dual ironworker2. punching machine
3. shearing machine
4. notching machine
5. gain time
Dual ironworker (Q35Y-30)
Features:
EMM’s universal multi – function Ironworker machine for production purposes with maximum efficiency and minimum deformation. The Q35Y-30(140 ton) pressure machines are in the EMM’s tradition of well engineered, robust steelworkers built for long working life.
The universal machines are supplied with standard tooling include repetition support table at punching, shearing and notching stations and with easily adjust hold down at five stations to safely and control the operations, comprehensive safety guards are fitted as standard on all working stations.
Free standing on suitable floor, the ironworker machines just require electrical connection to be ready for work. For two operator utilization, the hydraulic system is activated by two shielded for switch control , one operating the punching end cylinder, the other operating shearing end cylinder, the shear cylinder provides the power to three shearing stations and notching station.
The system gives precision accurate power inching at all give five works stations and allows the ironworker machine to be stop at any position giving safe and accurate tool setting and working positioning. Limit switches at both ends of the machine control stroke length at all stations.
No. |
Descriptions
|
Model |
Unit (mm) |
|
1.Machine Technical Data
|
Single Hydraulic Steel Worker Machine |
Q35Y-30 |
Metric |
|
2.Flat Plate Cutting Station
|
Flat Plate Shearing Maximum Width x Thickness |
380x 30 |
mm |
|
Flat Plate Shearing Maximum Width x Thickness |
600x20 |
mm |
|
Angle Flange Trim Maximum 45° |
120x15 |
mm |
|
Working height |
890 |
mm |
|
|
3.Angle Cutting Station
|
90° Miter (True Interior /Exterior ) |
180x16 |
mm |
45° Miter (True Interior /Exterior ) |
80x10 |
mm |
|
Working Height |
1155 |
mm |
|
|
4.Section Cutting Station
|
Round Bars Maximum Diameter |
55 |
mm |
Square Bars Maximum Diameter |
65 |
mm |
|
Channel C or U /I or H Beams( Optional ) |
300 x 100
|
mm |
|
Tee ( Optional ) |
100 x 12 |
mm |
