Help CenterEEC08 Double Head Riveting Machine
Related Products
-
EEC08 Rivet Setting MachineUS$ 4,800 - 6,500MOQ: 1 Set -
EEC08 Hollow Riveting MachineUS$ 4,800 - 6,500MOQ: 1 Set
-
EEC08 Foot Pedal Operated Riveting MachineUS$ 4,800 - 6,500MOQ: 1 Set
-
ECR03 Rivet Heading MachineUS$ 4,800 - 6,500MOQ: 1 Set
-
ECR03 Plastic Rivet MachineUS$ 4,800 - 6,500MOQ: 1 Set
Specifications
Foot Pedal Operated Riveting Machine1 rivet one workpieces
2 the EEC08 mechanism
3 high rigidity,high strength
4 no vibrati
Hand Operated Riveting Machine
Features
1.The foot pedal operated riveting machine enables to rivet one workpieces at time.
2.The die installation is realized by applying the EEC08 mechanism which also safety ensures the exact alignment of die.
3.This product is designed with integral cast steel structure featuring high rigidity,high strength and high quality to guarantee adequate die installation space.
4.As producing no vibration and impact,it can improve the working environment to a certain degree. The soft in-position function protects the die from impact, thus prolonging the die life and greatly increasing the product qualification rate.
5.Combing the characteristics of and the practical application situation, we apply the rely logic circuit control and the pure compressed air drive system to this equipment.
6. It comes with the foot pedal for staring up.The hydraulic sensor well controls the press fitting quality and the returning of upper die.Meanwhile,the power stroke realizes self locking.
7.The solid cast construction of the foot pedal operated riveting machine safety guarantees the high accuracy of upper and lower dies during riveting,The 500mm throat depth makes it applicable for connecting various specifications of metal plates.
Name |
pressurized oil-air cylinder clinching machine |
Model |
EEC08 |
Machine No. |
12051720 |
The supercharger oil cylinder No. |
12045185 |
Total travel |
100 mm |
Power travel |
10 mm |
Max oil pressure |
6 bar |
Max. force |
76 KN |
Control system |
STE-01-F-08 |
Power supply |
220V/60HZ |
Control electrical source |
DC24V |
Power |
50W |
Rated minimum pressure |
3 bar(Below this pressure equipment action will be difficult) |
Rated maximum pressure |
6 bar(Higher than the air pressure equipment will be damaged) |
Gas spring set air pressure |
0.5bar(Below this pressure equipment will return difficult, higher than the air pressure equipment will be smaller output) |
Air source |
Require the compressed air by filtering and drying |
Special notice |
Compressed air through the dry processing, or reduce the service life of the equipment |
Evironment temperature |
-5~40°C Non-condensate |
Atitude |
<=1200m |
Rlative humidity |
<=85% |
