ZT-1000mm PE Air Bubble Wrap Film Making Machine ZT100-7S
Packaging Details: Air bubble film and stretch film
Delivery Detail: 30 days
ZT-1000mm PE Air Bubble Wrap Film Making Machine ZT100-7S is to produce air bubble film.
Optional Equipment:
1)Auto loader
2)Auto dry hopper
3) Quick screen changer
4)Hydraulic net changer
5)Air shaft
6)lamination rack with tension
7)Auto edge recycling system
8)Auto roll changer
Main technical parameters:
Model |
ZT-1800 |
ZT-1500 |
ZT-1000 |
Main and auxiliary extruder screw diameter |
φ85mm |
φ75mm |
φ55mm |
L/D |
30:1 |
30:1 |
30:1 |
Main and auxiliary extruder electrical power |
30KW |
22KW |
18.5KW |
Width of production |
1800 mm |
1500 mm |
1000 mm |
Main bubble specification(arbitrary eligibility) |
φ6×3.2mm φ10×3.4mm φ25×10mm φ30×10mm |
||
Output |
163-245kg/h |
150-220kg/h |
123-180kg/h |
Total Power |
278kw |
210kw |
1750kw |
Overall dimension |
7.5m×2.8m×2.5m |
7.5m×2.5m×2.5m |
7.0m×2.0m×2.5m |
Gross weight |
16.2T |
13.9T |
11.7T |
