Home > Products > New Products > 2013 New designed automatic humidistat control dehumidifier low price
2013 New designed automatic humidistat control dehumidifier low price
- 50000 Unit / Units per Month
- Ningbo/shanghai
- T/T Credit Card PayPal
- High quality hazardous area thermostat OEM
- High quality explosion protection thermostat temperature controller OEM
- High quality indoor thermostat air cooler CE
- High quality thermostatic bimetal strip indoor CE
- 24V&48VDC electronic overload relay 16A wholesale
- High quality communicating thermostat temperature controllers 230VAC
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Saip | Model Number: | MFR 012 |
Usage: | Industrial | Theory: | Hygrometer |
Packaging Details
Standard export package
Product Description
Specifications
mechanical humidistat1.Adjustable relative humidity
2.Simple to accessible
3.High switching performance
4.OEM, CE&RoHS
2013 New designed automatic humidistat control dehumidifier low price
Introduction for Mechanical Humidistat :
Hygrostat switches on the heater or fan when a pre-set relative humidity in the enclosure is exceeded.
The relative humidity is raised above the dew point, and condensation on electrical equipment is avoided option for vertical or horizontal mounting.
The electromechanical hygrostat MRF 012 is designed to control enclosure heaters so that the dew point is raised when a critical relative humidity of 65% is exceeded. In this way condensation and corrosion is effectively prevented.
Mechanical Humidistat Advantage:
1.Adjustable relative humidity
2.Change-over contact
3.High switching capacity
4.Easily accessible terminals
5.Clip fixing
Mechanical Humidistat Technical Date:he
Switch difference | 4% RH (±3% tolerance) |
Permissible air velocity | 15m/sec |
Contact type | change-over contact |
Contact resistance | < 10mOhm |
Service life | > 100 000 cycles |
Min. switching capacity | 20V AC/DC 100 mA |
Max. switching capacity | 250 VAC, 5 (1) A |
DC 20W | |
EMC | acc. to EN 55014-1-2, EN 61000-3-2, EN 61000-3-3 |
Connection | 3-pole terminal for 2.5mm², clamping torque 0.5Nm max.: rigid wire 2.5mm², stranded wire (with wire end ferrule) 1.5mm² |
Mounting | clip for 35mm DIN rail, EN50022 |
Casing | plastic according to UL94 V-0, light grey |
Dimensions/ weight | 67 x 50 x 38mm approx. 60g |
Fitting position | variable |
Operarting/Storage temperature | 0 to +60°C (+32 to +140°F) / -20 to +80°C (-4 to +176°F) |
Protection type | IP20 |
Mechanical Humidistat
Mechanical Humidistat Product Details:
t
Example of Mechanical Humidistat Connection:
Mechanical Humidistat
You May Need Other Series Thermostat:
Mechanical Humidistat
About us:
Saip Electric Group Co., Ltd (called "Saip" for short) is an enterprise specialized in design, production and sales of electric equipments.
Head office located in the largest manufacturing base of electric equipment of Wenzhou China, which is called "the Electric Equiment Capital of China".
We have 5 specialized branches,over 300 specialized cooperative partners.
Saip,an ISO9001 certificated enterprise.
With 20 years of development history, Zhejiang Saip Electric Co., Ltd. has become a modern enterprise integrating the production,sale with research.
Mechanical Humidistat
thermostat high switching performance Mechanical Humidistat smallcompact Mechanical Humidistat large setting thermostat easily accessible Mechanical Humidistat hot sale Mechanical Humidistat adustable relative Mechanical Humidistat 35 to 95& RH Mechanical Humidistat
Certificates:
thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat hot sale thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat
Our Service:
Skype:saip3321
Tel: +86 0577-6177 0786
1.Please kindly inform us which items you are interested & the reasonable price will be providedyou upon receipt of your new inquiry ASAP.
2.Answer your question detailed
3.Solved the problem with you during using our products
4. Samples will be offered to you for our future cooperation.
thermostat high switching performance Mechanical Humidistat smallcompact Mechanical Humidistat large setting thermostat easily accessible Mechanical Humidistat hot sale Mechanical Humidistat adustable relative Mechanical Humidistat 35 to 95& RH Mechanical Humidistat
....
Company Profile
Our company (called "Saip" for short) is an enterprise specialized in the design, production and sales of electric equipment. Our office is located in the largest manufacturing base of electric equipment of Wenzhou, which is called "the Electric Equipment Capital of China".
Saip has five specialized branches, and over 300 specialized cooperative partners. Saip, an ISO9001 certificated enterprise, has modern production lines and high quality controlling equipment with scientific administration, professional engineers, highly trained teams, technicians and skilled workers.
Now, Saip has five design and production bases in Hong Kong, Taiwan, Singapore, Turkey and Wenzhou (China Mainland) respectively, 28 sales organizations in the world and more than 50 holding member enterprises.
Saip products cover low-voltage apparatus, welding equipment, instruments and meters, photoelectrons, and electrical products for construction, automobile apparatus and industrial automation. The products are sold to more than 100 countries and regions. All exported products have passed the certification of CE and partial products have passed several kinds of international certifications like RoHS, TUV, UL, KEMA, S, SIRIM and so on. Saip as always insists on the tenet of "high quality and sincere service".
Saip will be your successful cooperative partner.
