Specifications
Small, compact thermostat1.High quality,great function
2.Simple to mount
3.High switching performance
4.CE&RoHS
Latest price for analog control thermostat CE&RoHS
Introduction for Thermostat:
Two thermostats in one casing:
1.Thermostat (normally closed) contact breaker for regulating heaters.
2.Thermostat (normally open) contact maker for regulating filter fans and heat exchangers or for switching signal devised when temperature limit has been exceeded.
3.Heaters and cooling equipment can be switched independently from each other with a temperature offset as opposed to the usual change-over contacts.
Thermostat Application:
For the control of warm-water(floor)heating systems and direct electric heating systems used in Commercial buildings,Residential buildings, Light in dustrial buildings,etc.
Thermostat Technical Date:
| Technical Data | |
| Switch temperature difference | 7K (± 4K tolerance) |
| Sensor element | thermostatic bimetal |
| Contact type | snap-action contact |
| Service life | > 100,000 cycles |
| Max. Switching capacity | 250VAC, 10 (2) A |
| 120VAC, 15 (2) A | |
| DC 30W | |
| EMC | acc.to EN 55014-1-2,EN61000-3-2,EN61000-3-3 |
| Connection | 2-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm² stranded wire (with wire end ferrule) 1.5mm² |
| Mounting | clip for 35mm DIN rail, EN60715 (or for exit filter EF 118 Series) |
| Casing | plastic according to UL94 V-0, light grey |
| Dimensions | 60 x 33 x 43mm |
| Weight | approx. 40g |
| Fitting position | variable |
| Operating / Storage temperature | -20 to +80°C (-49 to +176°F) |
| Operating / Storage humidity | max. 90 % RH (non-condensing) |
| Protection type | IP20 |
thermostat
Thermostat Product Details:


| Setting range | Art. No. Contact Breaker (NC) | Art. No. Contact Maker (NO) | Approvals |
| 0 to +60°C | 01140.0-00 | 01141.0-00 | VDE |
| -10 to +50°C | 01142.0-00 | 01143.0-00 | VDE + UL File No. E164102 |
| +20 to +80°C | 01159.0-00 | 01158.0-00 | VDE + UL File No. E164102 |
| +32 to +140°F | 01140.9-00 | 01141.9-00 | VDE + UL File No. E164102 |
| +14 to +122°F | 01142.9-00 | 01143.9-00 | VDE + UL File No. E164102 |
| 0 to +60°C | 01146.9-00 | 01147.9-00 | VDE + UL File No. E164102 |
tthermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat hot sale thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat
Example of Thermostat Connection:


thermostat
You May Need Other Series Thermostat:
thermostat
About us:
Saip Electric Group Co., Ltd (called "Saip" for short) is an enterprise specialized in design, production and sales of electric equipments.
Head office located in the largest manufacturing base of electric equipment of Wenzhou China, which is called "the Electric Equiment Capital of China".
We have 5 specialized branches,over 300 specialized cooperative partners.
Saip,an ISO9001 certificated enterprise.
With 20 years of development history, Zhejiang Saip Electric Co., Ltd. has become a modern enterprise integrating the production,sale with research.
thermostat

thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat hot sale thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat
Certificates:
thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat hot sale thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat
Our Service:
Skype:saip3321
Tel: +86 0577-6177 0786
1.Please kindly inform us which items you are interested & the reasonable price will be providedyou upon receipt of your new inquiry ASAP.
2.Answer your question detailed
3.Solved the problem with you during using our products
4. Samples will be offered to you for our future cooperation.
thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat hot sale thermostat high switching performance thermostat smallcompact thermostat large setting thermostat easily accessible thermostat
....
