2012 NEW 110/24v Control Transformer 100VA

2012 NEW 110/24v Control Transformer 100VA thumbnail-1
2012 NEW 110/24v Control Transformer 100VA photo-1
US$ 10 - 100 MOQ: 100 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Saip
Model Number:
BK
Contact Supplier Request Quote Chat Now
Yueqing Saip Electric Company Limited
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Saip
Model Number BK
Usage Other, control transformer
Phase Single
Coil Structure Toroidal
Coil Number Autotransformer

Specifications

2012 NEW 110/24v control transformer apply to be used as control power, working light of general electric appliance

2012 NEW 110/24v control transformer 100VA



machine tool control transformers apply to be used as control power, working light of general electric appliance and mechanical equipment of various trades, and power of signal lamp with AC50-60HZ, input voltage doesn’t exceed 500V, output voltage doesn’t exceed 220V.





NP1 Series transformer
Type Rated power (VA) Rated input voltage(V) Rated output voltage(V)
NP1-40 40 Control illumination indication
NP1-63 63 220±5% 110(127) 24(36) 6(12)
NP1-100 100
NP1-160 160
NP1-250 250
NP1-300 300
NP1-400 400
NP1-630 630
NP1-800 800
NP1-1000 1000
NP1-1600 1600 Distribution of capacity for different windings
NP1-2500 2500 would be according to the users requirements



Type Rated power (VA) Installing dimensions Outline dimensions Cavity
A C B D E F K or K×J
NP1-40 40 56±0.5 51±2 78 70 86 2 4.8×9
NP1-63 63 56±0.5 51±2 78 70 86 2 4.8×9
NP1-100 100 64±0.5 67±2 85 85 93 2 4.8×9
NP1-160 160 84±0.5 74±2 96 90 103 2 5.8×11
NP1-250 250 84±0.5 88±2 96 105 103 2 5.8×11
NP1-300 300 84±0.5 96±2 96 115 103 2 5.8×11
NP1-400 400 90±0.5 90±2 120 113 123 2.5 7×13
NP1-630 630 122±0.5 86±2 150 118 145 2.5 7×13
NP1-800 800 122±0.5 100±2 150 128 145 2.5 7×13
NP1-1000 1000 127.5±2 152±2 155 205 145 3 7×12
NP1-1600 1600 140±2 176±2 180 230 160 3 7×12
NP1-2500 2500 173±2 200±2 205 260 175 4 7×12



 2012 NEW 110/24v control transformer 100VA
