Saipwell PV Solar Control PWM Regulator
US$ 23 - 28
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Saip solar charge controller
Model Number:
SMG30
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Solar Generator System for Home Use SP-600US$ 20 - 500MOQ: 100 Pieces -
Portable Solar Generator 1000w SP-500US$ 20 - 500MOQ: 100 Pieces
-
30kw Solar Generator System SP-1000US$ 20 - 500MOQ: 100 Pieces
-
Solar Generator 400wp S-1207US$ 20 - 500MOQ: 100 Pieces
-
Solar Generator With the Lithium-ion Battery S-1207US$ 20 - 500MOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
Saip solar charge controller
Model Number
SMG30
Application
Charger Controller
Rated Voltage
12V
Maximum Current
30A
Specifications
Saipwell PV Solar Control PWM Regulator1.battery state-of-charge display with 3 LEDs
2.PWM-regulation
3.CE
Saipwell PV Solar Control PWM Regulator
Product Description
Function:
1.battery state-of-charge display with 3 LEDs
2.acoustic load disconnect pre-warning
3.PWM-regulation(series type)
4.boost,equalize and float charging, also for VRLA
5.automatic 12/24 volt detection
6.integrated temperature compensation
7.large terminals ( up to 16mm2 wire size )
8.SOC and voltage controlled LVD
9.fully eletronically protected
Technical data:
| model | SMG30 |
| noinal voltage | automatic recognition 12/24v,48v |
| lar panel current | 30a |
| Max.load panel current | 30a |
| boost voltage | 14.5v/29.0v |
| equalization voltage | 14.8v/29.6v |
| folat voltage | 13.7v/27.4v |
| deep discharge protection |
11.4-11.9v/22.8-23.8v controlled by statc of charge 11.0/22.0v controlled by voltage |
| load reconnect voltage | 12.8v/25.6v |
| consumption | -4mv/cell x K |
| Max.wire size | 16mm^2 |
| dimensions (WxHxD) | 98x122x49mm |
| weight | 400g |
| temperature range | -20°C to + 50 °C |
| type of protection | IP44 |
Product show
Packaging & Shipping
Packing detail: standard export packing
Shipping detail : within 5 days after getting payment
Our Services
Inquiry: we will give your reply in 24 hours.
Shipment: sea transportation, air transportation or express, fast delivery .
Payment: T/T , Paypal.
Warranty : 1~3 years.
We provide best OEM service.
