Specifications
PWM Solar Control Charger Solar Generation Controller1.One programmable nightlight function
2.PWM
3.2 years warranty
4.CE
Saipwell PWM Solar Control Charger Solar Generation Controller
Introduction:
The SMLNL series is a sophisticated solar charge controller family for low cost applications.
The electronic circuit is equipped with a microcontroller that provides high-efficiency chargingtechnology together with a number of outstanding status display,warning and safety functions.
Function:
1.one programmable nightlight function
2.PWM-regulation(series type)
3.three-state charging method
4.integrated temperature compensation
lid-state circuit and load protection
6.SOC and voltage controlled LVD
7.fully eletronically protected
8.reverse polarity protection
Technical data:
|
model
|
SMLNL05 | SMLNL08 | SMLNL10 | SMLNL15 | SMLNL20 |
lar panel current |
5A | 8A | 10A | 15A | 20A |
| Max.load current | 5A | 8A | 10A | 15A | 20A |
| boost voltage | 14.5v/29.0v | ||||
| dimensions( W x H x D ) | 80*100*32mm | ||||
| nominal voltage | 12/24V, automatic recognition | ||||
| equalization voltage | 14.8/29.6V | ||||
| float voltage | 13.7/27.4V | ||||
| deep discharge protection | 11.4-11.9/22.8-23.8V,controlled by statc of charge 11.0/22.0v, controlled by voltage | ||||
| load reconnect voltage | 12.8/25.6v | ||||
| temperature compensation | -4mV/cell*K | ||||
| lar panel current | 5/8/10/15/20a,according to model number | ||||
| Max.load current | 5/8/10/15/20a,according to model number | ||||
| weight | 183g | ||||
| Max.wrie size | 16mm^2 | ||||
| self consumption | <4ma | ||||
| temperature range | -20 to + 50 °C | ||||
| type of protection | IP22 | ||||
Packing detail: standard export packing
Shipping detail : within 5 days after getting payment
Inquiry: we will give your reply in 24 hours.
SAIP MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international IEC normative.
More details,please contact with us!
