Help Center2014 High Quality PTC Starter Relay (SHC69A)
Related Products
-
2014 High Quality Relay Contactor Timer (SHC69A)US$ 1 - 5MOQ: 1 Piece -
Saipwell Elevator Relay Off Delay Timer RelayUS$ 0.5 - 3MOQ: 100 Pieces
-
Saipwell High Power Relay Air Conditioner RelayUS$ 0.5 - 3MOQ: 100 Pieces
-
Saipwell 12v Relay 5 Pin Timer Relay PCBUS$ 0.5 - 3MOQ: 100 Pieces
-
Saipwell Horn Relay Electronic Motor Protection RelayUS$ 0.5 - 3MOQ: 100 Pieces
Specifications
ptc starter relay1.newly design
2.good quality
2014 High Quality PTC Starter Relay (SHC69A)
PTC Starter Relay Feature
1.Small volume, light weight, high sensitivity, long service life
2.Available in 1groups(10A/16A),2 groups (5A)of contact conversion
3.Can provide PCB printing plate, a socket type, flange mounted
4.Optional indicator and the diode
PTC Starter Relay Paramaters
PTC Starter Relay
| Contact | Form | 1Z,1H,1D 2Z,2H,2D, | |
| Rated Load (Resistive Leakage) | 10A,16A 5A 240V/AC 28V/DC |
||
| Contact resistance (initial) | ≤100mΩ | ||
| Material | Silver alloy | ||
| Electric life | ≥105 | ||
| Machine life (300 times/min) | ≥107 | ||
| Max. allowed voltage (23℃) |
DC:≤75%×rated voltage AC:≤80%×rated voltage |
||
| Release voltage ( 23℃ ) |
DC:≥10%×rated voltage AC:≥30%×rated voltage |
||
| Maximum allowed voltage ( 23℃ ) | 110%×rated voltage | ||
| Norminal voltage | DC | DC:3v-110v | |
| AC | AC:6v-240v | ||
| Coil power | DC:0.53W | ||
| AC:1.0vA | |||
| Pick-up time (rated voltage) | ≤20ms | ||
| Release time (rated voltage) | ≤10ms | ||
| Initial withstand | Between same-pole contacts | 1200VAC/1min(leakage current:1mA) | |
| 1200VAC/1min(leakage current:1mA) | |||
| Between contact and coil | 5000VAC/1min | ||
| Insulation resistance | ≥100mΩ(500VDC) | ||
| Ambient temperature | -25℃~55℃ | ||
| Ambient humidity | 35%-80%RH | ||
| Atmospheric pressure | 86-106KPa | ||
| Resistance resistance | 10G (sinusoidal half-wave pulse: 11ms) | ||
| Vibration resistance | 10-55Hz (double amplitude: 1.5mm) | ||
| Installation | PCB, , Flange | ||
| Packing | Inner box | 100relays in each bubble box | |
| Outer case | 500relays in each case |
||
| Dimension of outer case | 500pcs:350*265*325MM |
||
| Weight | Gross9.4kg/box |
||
PTC Starter Relay
PTC Starter Relay Show
PTC Starter Relay
PTC Starter Relay
PTC Starter Relay Product
PTC Starter Relay
PTC Starter Relay
Certificate
PTC Starter Relay
PTC Starter Relay
Saip Company
Saip Electric Group Co., Ltd (called "Saip" for short) is an enterprise specialized in design, production and sales of electric equipments.
Head office located in the largest manufacturing base of electric equipment of Wenzhou China, which is called "the Electric Equiment Capital of China".
We have 5 specialized branches,over 300 specialized cooperative partners.
Saip,an ISO9001 certificated enterprise.
With 20 years of development history, Zhejiang Saip Electric Co., Ltd. has become a modern enterprise integrating the production,sale with research.
