Help CenterAutomatic Double Side Station Compression Molding Machine/rubber Platen Vulcanizing Press Machine
Related Products
-
Fully Automatic Push and Pull Mold Rubber Vulcanizing MachineUS$ 1,000 - 10,000MOQ: 1 Set -
Rubber Seal Making Machines/rubber Vulcanizing PressUS$ 1,000 - 10,000MOQ: 1 Set
-
Rubber Mat Making MachineUS$ 5,000 - 7,000MOQ: 1 Set
-
150t Rubber Molding Press MachineUS$ 5,000 - 7,000MOQ: 1 Set
-
100t Rubber Hydraulic PressUS$ 5,000 - 7,000MOQ: 1 Set
Application:
The machine is mainly used for producing mould press products, such as rubber products, thermoset plastic and thin rubber sheet product.
With automatic control method, improving the production effiviency and reduce the defective rates.
Structural features:
Former top open mold is used for a variety of two-story or three story mold pattern, is a multi-funnctional model.
Correct the mold function automatic with slow speed, at the same time the processes are more accurate and safer.
Access the loacation accurately and have a 100% safety design to ensure the mold positioning nondestructive.
Speed of the lift-shut are adjustable, accurate and reliable.
| Type | 100T | 150T | 200T | 250T |
| Norminal force ( MN ) | 1.0 | 1.5 | 2.0 | 2.5 |
| Heating plate size ( mm ) | 500 X 500 | 550 X 550 | 600 X 600 | 750 X 750 |
| Max. Working Pressure ( Mpa ) | 15 | 15 | 15 | 15 |
| Plate daylight ( mm ) | 125 | 125 | 125 | 200 |
| Number of working layer | 1 | 1 | 1 | 1 |
| Stroke of piston ( mm ) | 250 | 250 | 250 | 300 |
| Unit Area Pressure of Hot Plate ( Mpa/cm) | 2.0 | 2.2 | 2.5 | 2.8 |
| Motor Power ( KW ) | 5.5 | 5.5 | 5.5 | 7.5 |
| Overall diamension ( mm )(LxWxH) | 2200x1400x1750 | 2300x1500x1850 | 2400x1600x1900 | 2800x1800x1950 |
| Weight ( kg ) | 4000 | 5500 | 7500 | 9500 |
Sigle side automatic molding machine
We are QINGDAO Jinrunqi Rubber Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email
Also we can make non-standard rubber machinery as customer’s requirements.
