Specifications
heat shrink sleeve for pipesheat shrinking tube, which is flexible, flame-retardant
2012 NEW heat shrink sleeve for pipes
Polyolinfin heat-shrinkable single wall tube
Material: Polyolefin
Srink Ratio: 2:1/3:1
Flexible, flame retardant .Technical Data
| Item | Specifications | |
| Shrink Temperature(°C) | 90 | |
| Temperature Range(°C) | 125 | |
| Radial Shrinking Ratio(%) | ≥50 | |
| Longitudinal Change(%) | ≤5 | |
| Tensile Strength(MPa) | ≥10.4 | |
| Ultimate Elongation (%) | ≥200 | |
| Aging in Circulating-air Oven | 158.0±1.0°C, 168hrs | |
| After aging | Tensile Strength(MPa) | ≥7.3 |
| Ultimate Elongation(%) | ≥100 | |
| Volume Resistivity(Ω.cm) | ≥1014 | |
| Dielectric Strength(KV/mm) | ≥15 | |
| Flammability | VW-1 | |
| Concentricity(%) | ≥65 | |
SIZE
Size As Supplied (mm) After Recovery (mm) Inside Diameter Wall-thickness Inside Diameter Wall-thickness φ0.8 1.3±0.2 0.15±0.05 ≤0.45 0.28±0.05 φ1.0 1.5±0.2 0.18±0.05 ≤0.6 0.30±0.05 φ1.5 2.0±0.2 0.18±0.05 ≤0.8 0.32±0.05 φ2.0 2.5±0.2 0.18±0.05 ≤1.00 0.35±0.05 φ2.5 3.0±0.2 0.20±0.05 ≤1.25 0.38±0.05 φ3.0 3.5±0.3 0.20±0.05 ≤1.5 0.38±0.05 φ3.5 4.0±0.3 0.20±0.05 ≤1.75 0.38±0.05 φ4.0 4.5±0.3 0.23±0.05 ≤2.0 0.45±0.05 φ4.5 4.8±0.3 0.23±0.05 ≤2.25 0.45±0.05 φ5.0 5.5±0.3 0.23±0.05 ≤2.5 0.45±0.05 φ6.0 6.5±0.4 0.25±0.05 ≤3.0 0.50±0.05 φ6.5 7.0±0.4 0.25±0.05 ≤3.0 0.52±0.05 φ7.0 7.5±0.4 0.30±0.08 ≤3.5 0.60±0.05 φ8.0 8.5±0.3 0.30±0.08 ≤4.0 0.60±0.08 φ9.0 9.5±0.4 0.30±0.08 ≤4.5 0.60±0.08 φ10 10.5±0.5 0.30±0.08 ≤5.0 0.60±0.08 φ11 11.5±0.5 0.30±0.08 ≤5.5 0.60±0.08 φ12 12.5±0.5 0.30±0.08 ≤6.0 0.60±0.08 φ13 13.5±0.5 0.36±0.12 ≤6.5 0.65±0.12 φ14 14.5±0.5 0.36±0.12 ≤7.0 0.65±0.12 φ15 15.5±0.5 0.36±0.12 ≤7.5 0.65±0.12 φ16 16.5±0.5 0.36±0.12 ≤8.0 0.70±0.12 φ17 17.5±0.5 0.36±0.12 ≤8.5 0.70±0.12 φ18 18.7±0.5 0.40±0.15 ≤9.0 0.75±0.12 φ20 20.6±0.6 0.40±0.15 ≤10.0 0.80±0.12 φ22 22.7±0.6 0.40±0.15 ≤11.0 0.80±0.12 φ25 25.5±0.7 0.45±0.15 ≤12.5 0.90±0.12 φ28 29.2±0.7 045±0.15 ≤14.0 0.90±0.12 φ30 31.0±0.7 0.45±0.15 ≤15.0 0.90±0.12 φ35 ≥35 0.50±0.15 ≤19 1.00±0.30 φ40 ≥40 0.50±0.15 ≤21 1.00±0.30 φ50 ≥50 0.50±0.15 ≤27 1.00±0.30 φ55 ≥55 0.50±0.15 ≤28 1.00±0.30 φ60 ≥60 0.50±0.15 ≤31 1.00±0.30 φ70 ≥70 0.70±0.30 ≤35.0 1.45±0.25 φ80 ≥80 0.70±0.30 ≤40.0 1.45±0.25 φ90 ≥90 0.70±0.30 ≤45.0 1.45±0.25 φ100 ≥100 0.70±0.30 ≤50.0 1.45±0.25
Packing
