Home > Packaging & Printing > Packing Machinery > Filling Machine > Automatic Pulp Juice Filling Monobloc Machine
US$ 17,500 - 95,300
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
500ml, 1L, 1.5L Bottle Juice Hot Filling MachineUS$ 17,500 - 95,300MOQ: 1 Set -
Small PET Bottle 5000b/h Juice Filling MachineUS$ 17,500 - 95,300MOQ: 1 Set
-
Automatic Juice Bevarage Filling Machine For Small PET BottlesUS$ 17,500 - 95,300MOQ: 1 Set
-
Big Capacity Automatic Hot Filling Monobloc MachineUS$ 17,500 - 95,300MOQ: 1 Set
-
High Quality Good Price Juice Hot Filling MachineUS$ 17,500 - 95,300MOQ: 1 Set
Condition
New
Application
Beverage
Packaging Type
Bottles
Packaging Material
Plastic
Automatic Grade
Automatic
Driven Type
Electric
Voltage
Customized
Power
6kw
Place of Origin
Jiangsu, China
Brand Name
ERUSUN
Model Number
RHFC
Dimension(L*W*H)
5000*3600*2600
Weight
11000kg
Certification
ISO CE
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
ERUSUN Pulp juice 4-in-1 filling machine is a set of rinsing, pulp filling, juice filling and capping in one of the moderate (high) temperature filling machine, pulp, juice separately filling solve the problem of uneven content.
Host fully enclosed sealed windows, filling part 100 clean to ensure that the environment in the filling area to reach the desired temperature and filling requirements.
Bottle conveying adopts NECK HOLD, to reduce the adjustment and operation to the machine when changing bottle shape under the circumstance of keep the bottle mouth.
Host using reducer and coupling interaction transfer power to ensure the smooth operation.
Technical Parameter
Technical Parameters
| Model | RHFC16/8/12/6P | RHFC18/12/18/6P | RHFC24/18/24/8P | RHFC32/18/32/10P |
| Rinsing Head | 16 | 18 | 24 | 32 |
| Pulp filling head | 8 | 12 | 18 | 18 |
| Juice Filling Head | 12 | 18 | 24 | 32 |
| Capping Head | 6 | 6 | 8 | 10 |
| Production capacity (500ml) (B/H) | 3000BPH | 5000BPH | 8000BPH | 11000BPH |
| PET bottle size (mm) | Bottle diameter φ50-φ100mm; Height 150-320mm | |||
| Rinsing water pressure (Mpa) | 0.2-0.25 | |||
| Rinsing water consumption (ton/h) | 1t/hour | 1.2t/hour | 2t/hour | 2t/hour |
| Air pressure (Mpa) | 0.7 | |||
| Air consumption (m3/min) | 0.25m3/min | 0.8m3/min | 0.8m3/min | 0.8m3/min |
| Motor power (KW) | 3.5 | 4 | 6 | 8 |
| Weight (KG) | 5500 | 7500 | 11000 | 13000 |
| Packing Size (L*W*H) (mm) | 3700*2300*2600 | 4300*3000*2600 | 5000*3600*2600 | 6000*4400*2600 |
