9.00*22.5 tubeless wheel rim for truck

Specifications

9.00*22.5 tubeless wheel rim for truck
1)Tubeless wheel size: 9.00*22.5
2)Weight: 46/51kgs
3)Color: Silver

9.00*22.5 tubeless wheel rim for truck

   DONGYING ZHENGYU WHEEL CO.,LTD is one of the most company of producing steel wheel. With 10 year in the field, we can service you with competitive price and the best quality.

The series of our product:

Tubeless wheel: 17.5*6.00, 17.5*6.75, 19.5*6.75, 19.5*7.5, 22.5*6.75, 22.5*7.50, 22.5*8.25, 22.5*9.00, 22.5*11.25, 24.5*8.25,

Tube wheel: 5.50-16, 6.00G-16, 6.50-16, 6.50-20, 7.0-20, 7.5-20, 8.0-20, 8.5-20, 8.5-24, 9.0-20



Wheel size	Bolt Hole			P.C.D  (mm)	Center Bore DIA  (mm)	DISC Thick  (mm)	Offset (mm)	TEC.TYPE	QTY/ 20GP
	Hole DIA(mm)	NO	Nut Type
22.5×9.00
22.5×9.00	Φ27	10	1*45	Φ335	Φ281	14           16	175	12R22.5      215/75R 22.5  298/80R 22.5  315/80R 22.5	280
22.5×9.00	Φ32	10	SR22	Φ285.75	Φ222		178
22.5×9.00	Φ26	10	1*45	Φ285.75	Φ221		175
22.5×9.00	Φ32	8	SR22	Φ285	Φ222		175
22.5×9.00	Φ32	8	SR22	Φ275	Φ214		175
