Large Power 3-phase Pure Sine Wave Solar Inverter for Industrial System
- NINGBO OR SHENGZHEN OR SHANGHAI
- T/T Money Gram Credit Card
You May Like
-
Hybrid System High Quality DC to AC Pure Sine Wave Solar Inverter
-
15000 Watt Without Battery MPPT100-500VDC 3 Phase off Grid Inverter
-
120VDC to 380V 3-phase Solar Power Inverter for 5kw Hybrid System
-
IP45 40kw 3 Phase Solar System Pure Sine Wave Hybrid Inverter
-
Wide Voltage Input High-power 50kw Pure Sine Wave Invertor
-
5kw 120VDC to 415VAC 3-phase Solar System Low Frequecy Power Inverter
Product Details
| Place of Origin | Zhejiang, China | Brand Name | BANGZHAO OR OEM | |
| Model Number | BZP-250KW | Output Power | 1 - 200KW | |
| Output Type | Triple | Size | 1200x1500x1800mm | |
| Weight | 900KG | Input Voltage | 600V | |
| Output Voltage | 380/400/415/440VAC optional | Type | DC/AC Inverters | |
| Output Frequency | 50 or 60 HZ | Output Current | 379A (phase current) |
Product Description
pure sine wave solar inverter
We can make products according to your requirements.
Technical Features:
1, Two kinds of start mode: Reduction Voltage Start and Variable Frequency Start. Customers can set start mode according to the type of the load.
2, The output frequency can be set, this function is very convenient for customer.
3, The output voltage can be set between +20 % to -40 % of rated voltage. It’s a great convenience to users.
4, The DC input voltage range can also be set. Over-voltage point, under-voltage point, over-voltage recovery point, under-voltage recovery point all can be set via the LCD panel. Convenient for increasing or reducing the quantity of batteries, photovoltaic modules also can be used flexibly.
5, Pure sine wave output. with good transient response less than 40MS, little harmonic distortion, higher conversion efficiency and stable output voltage.
6, Powerful data display and fault instruction function. LCD can display the DC input voltage, output frequency, phase voltage, phase current, AC bypass input voltage, output power KWH, time and date, temperature, fault code display.
7, Using the fifth generation efficient IPM intelligent module from Japanese Mitsubishi, high efficiency and stable performance. It with powerful protection function, the protection for short circuit, over load, over temperature is more safe and reliable. It’s service life can up to 15 years or more.
8, Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-500V or 200-850V.
9, Product have passed the European CE (EMC and LVD) certificated and accredited by Australia CEC energy network.
Technical Data
Model | BZP-200KW | BZP-250KW | ||
Isolation mode | Low Frequency Transformer | |||
DC Input | Rated voltage (Vdc) | 600V | ||
Rated current(A) | 333A | 417A | ||
AC Output | Rated output power | 200KW | 250KW | |
Output waveform | Pure Sine Wave | |||
Rated Voltage | 380VAC±3% | 380VAC±3% | ||
Phases | 3 phase 4 wire | 3 phase 4 wire | ||
Rated current(A) | 303A (phase current) | 379A (phase current) | ||
Frequency | 50Hz or 60Hz | |||
Rated output voltage range (V) | 380/400/415/440VAC optional | |||
Power Factor(PF) | 0.9 | |||
Overload Ability | 150%, 5 seconds | |||
Efficiency | >93% | |||
Waveform distortion rate (THD) | <3%(Linear load) | |||
DynamicResponse(0 to 100% load) | 5%,≤50ms | |||
Display | LCD | |||
Running mode | Working continuously | |||
Electrical insulation properties | 2000Vac, 1 Minute | |||
Protection Function | Protection | Input reverse polarity, under voltage, overvoltage, output over-current, short circuit, overheating etc. | ||
Cooling method | Fan-cooled | |||
Short-circuit protection | Noautomatic recovery, need to restart the machine | |||
Working environment | Noise ( 1 meter) | ≤50dB | ||
Degree of protection | IP20(indoor) | |||
Working Altitude(m) | ≤2000 | |||
Working temperature | -25~+55℃ | |||
relative humidity | 0~90%,non-condensing | |||
Mechanical dimension | Depth* Width * Height | 1200x1500x1800mm | ||
Weight (Kg) | 800Kg | 900Kg | ||
Above parameter only for reference ,could be custom made to user specifications.
