Home > Electrical & Electronics > Inverter > Power Inverter > 5 KW PV Grid Inverter

5 KW PV Grid Inverter

Name: 5 KW PV Grid Inverter
Brand: Powtech
SKU: 129447787
Availability: InStock

US$ 900 - 900 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

Powtech

Model Number:

SING5K

Contact Supplier Request Quote Chat Now

Qingdao Powtech Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name Powtech

Model Number SING5K

Output Power Other, 1 - 200KW, 5kw

Output Type Single

Size 430*630*286

Weight 65kg

Input Voltage 300 ~700VDC

Output Voltage 180~265VAC

Type DC/AC Inverters

Output Frequency 50/60Hz

Output Current 20A

SING5K grid inverter/5 KW PV Grid Inverter

Product Description

SING5K grid inverter/5KW PV Grid inverter

SING5K grid inverter are the grid inverters which have widest input voltage range. With whole closed structure, can be placed directly under the PV cell components, and is suitable for outdoor installation and operation.

Technical specifications:

Type	SING5K	SING6K
Max. DC power	6kWp	7.2kWp
Max. DC input voltage	780VDC
PV voltage range ,MPPT	300~700VDC
Max. number of strings (parallel)	3
PV board connection	Water proof in-line terminals
Max. input current	20A	24A
Max. AC output power	5kW	6KW
Nominal AC voltage	180~265VAC
Nominal AC frequency	50HZ/60HZ
Power factor	0.99
THD of AC current	<4%
Max. efficiency	95%
Euro efficiency	94%
Isolation	Low frequency transformers isolation
Internal power consumption an night	<10W
Comm. interfaces	RS485/RS232/GPRS/internet
Isolation resistance	1500Vac,1min
Operating Temp.	-20~+40
Relative humidity	0~90% non-condensing
Protection	Possess the protecting function of input over voltage, short voltage, contrary connection, output over current, short circuit, over heat, over load
Cooling method	Natural air-cooled
Noise	<40dB
Protection degree	IP65
