Online double conversion UPS

FOB Price

USD $120 - $120 / Unit

20 Units(Min.Order)

Supply Ability 30 Unit / Units per Month
Port Qingdao
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	JETPOWER
Model Number	PP	Phase	Single Phase
Protection	Other, Lighting/Over voltage/Short circuit/Overload	Output Voltage	220/230/240VAC
Type	On-line	Application	Telecommunications

Product Description

UPS power supply/ High Frequence Online UPS

Product Description

PP series use advanced PWM technology with double conversion technology to an optimum solution approaching a line-interactive cost. The expanded input range increases battery life by eliminating unnecessary or nuisance discharge and recharge. Double conversion and advanced AC line filtering assures your equipment well protected. Runtimes can also be expanded with additional batteries providing worry free for long blackout.

With disturbances such as power sags, surges, spikes, switching transients, brownouts or complete power failure, the potential is high for data damage or loss, file corruption and hardware deterioration, which is not always immediately detected. The PP series can provide protection from such problems. Included with each UPS is UPSilon2000 power management software provides user with useful management functions such as power event logging, remote monitor and unattended file saving when blackout.

With proven field experience all over the world, including some poorest power regions, the new generation of PP series provides an optimum choice for complete power protection on all networking and telecommunication equipment.

Technical parameters:

Model

6KVA

6KVA(L)

10KVA

10KVA(L)

(3/1)

15KVA(L)

(3/1)

20KVA(L)

(3/1)

Capacity (KW)

4.2KW

7KW

10.5KW

14KW

Input

Voltage, Frequency

176-276VAC, 1phase/3wire, 46~54Hz

304-478VAC, 3phase/5wire, 46~54Hz

Bypass voltage

176~261VAC

Current

23A

37A

39A

69A

91A

Power factor

0.98

Protection type

32A NFB

50A NFB

100A NFB

Generator

Support by any generator

Output

Waveform

True sine wave

Voltage regulation

220/230/240VAC +/-1%

Transient response

≤5% (50% - 100% -50%)

Voltage distortion

<2% THD, linear load, <6% THD, non-linear load

Frequency regulation

(50+0.05) Hz (battery mode)

Frequency slow rate

1 Hz/s

Overload

110∼150% for 30sec, then transfer to bypass and auto resume; 150% for 300ms

Crest ratio

3:1

Battery

Voltage

240VDC

Charge current (max.)

4.2A

Efficiency

88%

Transfer Time

0ms

Indicator

Three (3) LED and One (1) LCD

Interface

RS-232

Power management software (UPSilon 2000)

SNMP (Optional)

Power management through SNMP manager and Web browser

Ambient

Temperature

0~40 ; 32~104

Relative Humidity

0-95% non-condensing

Physical

Weight

84kg

35kg

93kg

38kg

38.5kg

55kg

Dimension (L*W*H, mm)

570×260×717

Production Line

Certifications

Packaging & Shipping

Why choose us

1.Excellent quality

2.Favored price

3.Experienced workers team

4.Professional after-sales service

5.Online UPS,Line interactive UPS,Offline UPS leading supplier in China

6.Customized
