110V 15K DC/AC 3 Phase Inverter 2k 5k 10k 15k 30k 30k/dc to ac Inverter 3 Phase/power Inverter
US$ 900 - 1,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
JETPOWER
Model Number:
ND110-3150
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1kw Low Frequency Wall Mounted Integrated Solar Power Inverter / Solar InverterUS$ 150 - 1,100MOQ: 1 Set -
5KVA 48VDC (80A) High Frequency Wall Mounted Integrated Solar InverterUS$ 150 - 1,100MOQ: 1 Set
-
4KVA 48VDC (80A) High Frequency Wall Mounted Integrated Solar InverterUS$ 150 - 1,100MOQ: 1 Set
-
5KVA 48VDC (60A) High Frequency Wall Mounted Integrated Solar InverterUS$ 150 - 1,100MOQ: 1 Set
-
4KVA 48VDC (60A) High Frequency Wall Mounted Integrated Solar InverterUS$ 150 - 1,100MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
JETPOWER
Model Number
ND110-3150
Output Power
1 - 200KW
Output Type
Triple
Size
550*485*1200MM
Weight
180
Input Voltage
110Vdc
Output Voltage
380Vac
Type
DC/AC Inverters
Output Frequency
50/60Hz
Output Current
39.47A
Product Description
1.Advance IGBT inverted technology
2.Multiple CPU intelligent control
3.Multiple protection function of over-voltage ,short circuit, over-temperature on input
4.Special industrial design to ensure the safety in worse environment
5.Reliable, filtering and stable sine wave output
6.Static bypass switch
7.with output isolation transformer
Tech. specs
| Model | ND110 | ND110 | ND110 | ND110 | ND110 | ND110 | |
| -3020 | -3050 | -3100 | -3150 | -3200 | -3300 | ||
| DC input | Rated DC input voltage (VDC) | 110Vdc | |||||
| Rated DC input current (A) | 20.2 | 50.6 | 98.8 | 148.4 | 198 | 297 | |
| DC input voltage range (VDC) | 110Vdc +/-20% | ||||||
| AC bypass input | Utility AC input voltage (VAC) | 380Vac±15% | |||||
| Rated AC input voltage (A) | 3 | 7.6 | 15.2 | 22.75 | 30.3 | 45.45 | |
| Bypass transfer time (ms) | ≤4 | ||||||
| AC output | Rated capacity (KVA) | 2KVA | 5KVA | 10KVA | 15KVA | 20KVA | 30KVA |
| Rated output power (KW) | 1.6 | 4 | 8 | 12 | 16 | 24 | |
| Rated output voltage and frequency | 380VAC/220VAC ,50Hz (3phase, 4wire) | ||||||
| Rated output current (A) | 3 | 7.6 | 15.2 | 22.75 | 30.1 | 45.45 | |
| Output voltage regulation (V) | 380Vac ±3% | ||||||
| Output frequency regulation(Hz) | 50Hz±0.05 | ||||||
| THD | ≤2% | ||||||
| 3phase unbalanced | ≤100% | ||||||
| Dynamic response (load 0←→100%) | 5% | ||||||
| Power factor | 0.8 | ||||||
| Overload | 150%, 10S | ||||||
| Crest factor | 03:01 | ||||||
| Efficiency at rated load | 91% | 92% | |||||
| Environment | Insulation strength (between input & output) | 2000VAC,1min | |||||
| Noise (1m) | ≤45dB | ||||||
| Temperature | -10℃~+50℃ | ||||||
| Humidity | 0~90%, no condensation | ||||||
| Altitude (m) | ≤2000 | ||||||
| Sizes | W* D * H, mm | 550×480×980 | 550×485×1200 | 800×600×2260 | |||
| Weight (kg) | 30 | 60 | 160 | 180 | 200 | 250 | |
| Protection | DC input reversely protection, DC input under voltage, overload, short circuit, over temperature | ||||||
Certifications
Shipping
Why choose us
1. Major manufacturer,Competitive price, good quality and on-time delivery
2. ISO9001:2008 certification
3. Many years' production experience
Our Services
1. Abroad site installation & training available any time
2. Best prices compared to same configuration
3. Customized product available
4. Good after-sale response
5. Small order accepted
6. Excellent workmanship
