Home > Electrical & Electronics > Inverter > Power Inverter > 220VDC/AC 2KVA Inverter

220VDC/AC 2KVA Inverter

Qingdao Powtech Electronics Co., Ltd.
220VDC/AC 2KVA Inverter thumbnail-1
220VDC/AC 2KVA Inverter photo-1
Negotiable MOQ: 50 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
JETPOWER
Model Number:
ND
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name JETPOWER
Model Number ND
Output Power 500 - 1000W
Output Type Single
Size 482*405*133
Weight 30KG
Input Voltage 220VDC
Output Voltage 230VAC
Type DC/AC Inverters
Output Frequency 50/60Hz
Output Current 9.0A

220VDC 2KVA Inverter

Product Description

220VDC 2KVA Inverter

Features:

(1) Using IGBT from Simen company as the power components

(2) Using America INTEL microprocessor,

(3) Adopt SPWM technology

(4) Full bridge circuit suitable for all kinds of loads.

(5) AC bypass transfer

(6) Perfect protection and warning functions

(7) High efficiency

(8) Large LCD display

Technical data sheet:

220VDC/AC inverter (1 phase output)

Model

ND 220

-1010

ND 220

-1020

ND220

-1030

ND220

-1050

ND220

-1100

ND220

- 1200

ND 220

-1300

ND 220

-1500

DC input

Rated DC input voltage (VDC)

220

Rated DC input current (A)

5.0

10

15.2

25

49

99

148

247

DC input voltage range (VDC)

180~300

Bypass

Utility

input

Utility AC input voltage (VAC)

220±15%

Rated AC input voltage (A)

4.5

9.0

13.6

22.7

45

91

136

227

Bypass transfer time (ms)

≤4

AC output

Rated capacity (KVA)

1.0

2.0

3.5KVA

5.0

10

20

30

50

Rated output power (KW)

0.8

1.6

2.8

4.0

8.0

16

24

40

Rated output voltage and frequency

220VAC, 50HZ

Rated output current (A)

4.5

9.0

13.6

22.7

45

91

136

227

Output voltage regulation (V)

220±3%

Output frequency regulation(Hz)

50±0.05

THD

≤2%

Dynamic response  (load 0←→100%)

5%

Power factor

0.8

Overload

150%,10s

Crest factor

3:1

Efficiency at rated load

90%

92%

Environment

Insulation strength (between input & output)

1500VAC, 1min

Noise (1m)

≤50dB

Temperature

-10 to +50degC

Humidity

0~90%

Altitude (m)

≤2000

Sizes

Rack tye (W* D * H, mm)

482×405×133

482×405×178

482×420×223

550×480×980

Weight (kg)

18

30

40

60

150

260

360

700

Protection

DC input reversely protection, DC input under voltage, overload, short circuit, over temperature



Production Line

 220VDC/AC 2KVA inverter

Certifications

 220VDC/AC 2KVA inverter

Packaging & Shipping



Why choose us

1.Excellent quality



2.Favored price



3.Experienced workers team



4.Professional after-sales service&local training guide on site



5.Online UPS,line interactive UPS,offline UPS leading supplier from China,ISO certificated



6.Customized
