(Factory Price) SMA Male Bulkhead Connector for Semi-rigid Cable Antenna
US$ 5,000 - 1,000,000
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
linkeson, linkeson
Model Number:
SMA male bulkhead connector for Semi-rigid cable antenna
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SMA Male Right Angle Gold Connector for RG58US$ 5,000 - 1,000,000MOQ: 100 Pieces -
Linkeson SMA Female Gold Connector for PcbUS$ 0.35 - 0.5MOQ: 100 Pieces
-
Wholesaler SMA Female Pcb rf ConnectionUS$ 0.35 - 0.5MOQ: 1 Piece
-
Sma Jack Coaxial Connector Pcb Panel MountUS$ 5,000 - 1,000,000MOQ: 1 Piece
-
RF Connector Sma Female for Pcb MountUS$ 0.35 - 0.5MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
linkeson, linkeson
Model Number
SMA male bulkhead connector for Semi-rigid cable antenna
Type
SMA
Application
Other, RF,automotive,power,microwave,audio and video,antenna,WIFI, RF,automotive,power,microwave,audio and video,antenna,WIFI
Gender
Other, Male, male
Specifications
1.SMA male bulkhead for Semi-rigid2.MIL-C-39012
3.IEC-169-15
4.CECC-22110
5.ISO9001 2008 Standard,short delivery time
SMA male bulkhead connector for Semi-rigid cable antenna
Series SMA are very popular thread coupling miniature coaxial connectors.Which have the excellent performances of high reliability,high mechanical strength,high durability,and optimum electrical properties, are widely used to connect RF coaxial cables for mobile communication equipments and electronic communication instruments.they are widely use in electronic instrument,communication equipment,internet system,microwave testing,cable assembly and metal plate.
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω | Dielectric Withstanding voltage | 1000V(r ms) | |||
| Frequency range | With flexible cable | 0~12.4GHz | Contact resistance | Center conductor | ≤3mΩ | |
| With semi-rigid/flexible cable | 0~18GHz | Outer conductor | ≤2mΩ | |||
| VSWR | With flexible cable | ≤1.15+0.02F | Durability | 500 Cycles | ||
| With semi-rigid/flexible cable | ≤1.05+0.02F | |||||
| Material And Plating | ||||||
| Body | Brass , gold plated or stainless steel passivated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Silicon rubber | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
