Specifications
China Best Quality Duplex Stainless Steel Pipe for Export1)S32205, S31803, S32750
2)OD : 1/8-72inch
Best Quality Duplex Stainless Steel Pipe for Export
1)S32205 duplex stainless steel pipe
2)OD : 1/8-48inch (8mm -1219mm)
3)Wall thickness:Sch5-Sch160 (1mm - 80mm)
4)Length:6m-9m
Product detail:
1. Commodity: Cold Draw Duplex Stainless Steel Seamless Pipe(S31803,Duplex Stainless Steel Seamless Pipe(S31803,S32205,S32750))
2. Size: O. D: 1/8 - 24 inch, W. T: SCH10S, SCH40S, SCH80S, SCH160S etc. Or Non-regular sizes as requested.
3. Standard: ASTM/ASME A789,A790,A312,A213
4. Grade: S31803,S32205,S32750 and other duplex material.
5. Manufacture process: Cold draw or Cold roll, Annealed&Pickled
6. Testing:
A.Visual and Dimension Check, Chemical Testing, Physical Testing, Eddy Current Test or Hydrostatic Test in accordance to specification A999/A999 M.
B.Ultrasonic test can be done by customer's request.
C.Mechanical Property test of Tensile Strength, Yielding Point, Elongation and Flattening test by Mechanical Test Machine and Hardness by Rockwell test.
7. Surface Treatment: Annealed, and pickled.
8. Length: To be Specificed or Random.
9. Marking: As per specification A999/A999 M.
10. Packing: Packing in bundles by polythene & strapped Securely and wrapped with plastic bag. If require, then pack into wooden box.
1.Material |
S31803, 32750, etc. |
2. Standard |
ASTM, ASME, DIN, EN, ISO,JIS, GOST, etc. |
3. Type |
Seamless |
4. Size range |
OD: from 6mm to 1000mm (NPS from 1/8' to 40') |
WT: from 0.7mm to 38mm (Schedule from 5S to XXS) | |
Length: fix length or un-fix length, Max 30meters | |
5. Produce process |
Pilgering and cold drawn |
6. Surface process |
Pickling and annealing |
AP tube | |
BA tube | |
7. Marking |
JW, GRADE, seamless, STANDARD, SIZE, HT NO. |
8. Package |
Bundles with waterproof cloth outside. |
or plywood box. | |
9. Min order quantity |
500 KG |
10. Sample |
Yes |
11. OEM accepted |
Yes |
12. Production capacity |
300 tons per month |
13. Payment term |
T/T or L/C. |
14. Certificate |
ISO 9001, PED |
15. Third party ertificate |
BV, LR, SGS, TUV, CCS, ABS, etc. |
- Our company has been dedicated to producing stainless steel seamless pipe since 2003, owning complete producing technology and abundant managing experience.
- The raw material such as mother tube, round bar we use is from Chinese biggest and well-known steel mill: Walsin Steel and Yongxing Steel.
- We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test, Hydraulic test and so on.
- We have ISO 9001 and PED certificate, and the Third Party Inspection Certificates such as TUV, BV, Lloyd’s, SGS, etc, also can be provided according to customers’ requirements,
- Wooden case package which is strong and suitable for sea transportation is our main method to pack the pipes. And the economical packing method such as packed in bundles is also welcomed by some customers.
- The tolerance control we use is D4/T4 (+/-0.1mm) on both inside and outside Diameter and Wall Thickness, which is much higher than international standard ASTM, DIN.
- The surface condition is one of our main advantages: in order to meet different requirements for surface condition, we have annealing and pickling surface, bright annealing surface, OD polished surface, OD & ID polished surface etc.
- In order to keep the inside surface of pipe clean and make it free from deburring, our company develops the unique and special technology --- Sponge Washing with high pressure.
- We have complete after-sale service to deal with the problems in time.
Factory Show
Equipment Show
Certificates Show
Project Show
