lignite drying fluidized bed coal furnace
Product application
Hot flue gas fluidized bed hot air furnace can supply heat for such equipments as rotary drier, vertical drier, hammer drier, indirect drier, dry-grinding plants for slag micro-powder, air swept coal mill or dry-grinding plants for pulverized coal, fertilizer granulator, powder drying tower waste-heat power generation for concurrent heating material mixing & seasoning, and also to dry and bake such industrial raw materials or products as slag, clay, filthy mud, carbide slag, complex fertilizer, industrial plaster, plasterboard, fine iron powder sulfur ore concentrate, laterite ore, siderite, Zinc leaching residues coal dust and coal slime.
Working characters
1.Wide application for fuel.
It can use raw coal whose heating capacity over 6270KJ/Kg, or various bituminous coal, anthracite, lignite, and even gangue whose heating capacity is 1500Kcal/Kg.
2.Temperature in chamber is about 1000 °C, outlet temperature of chamber is about 850 °C, stable and even.
3.High combustion efficiency, coal burn-off rate: 99%, thermal efficiency rate: 95%, carbon content in ash: 2%;
4. Non-coking, suitable for making cement mixture and filler for other building product;
5.Easy ignition, long-time banking fire, intermittent banking fire time up to 16~48 hours, no need to re-ignite when restarts the banking fire.
6.Adjustable outlet temperature of the hot gas, convenient heating gas pipeline.
7.Clean burning, low NOX flue gas, desulfurization inside furnace, and solid sulfur in coal slag.
8.Achieving automatic PLC control, low working temperature.
9.Long service life, less wearing parts, low maintenance expense
Combustion way
1 broken coal particles with diameter below 10mm are sent evenly into the fluidized bed of the furnace chamber with coal feeder.
2The high pressure blasts from the blower are injected by the equal pressure bellows into the furnace chamber through nozzle button pores on the distributor. The blasts from all directions from the air bed to support coal particles and charging material for fluidized boiling combustion.
3The coal particles and coal slag crash and split mutually till burning into cinders in high temperature.
The features of our combustion way:
1.Large contact area between air and fuel;
2.High relative motion speed;
3.Long burning of fuel in fluidized bed;
4.Fast burning speed, high burning rate;
5.Energy saving and environment protection.
We have developed long and good relationship with many shipping agents. Ocean freight partners are: APL, COSCO, OOCL, CSCL, MSC, etc. and train shipping is also available. The perfect shipping way and best service with lowest price are always provided for customers.
1)Pre-sale services: enthusiasm
Provide you the prophase plan, process flow design and manufacturer equipment according to your special demand.
2)Sale services: servant
Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3)After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to customers.
Service Commitment
The product has a warranty period of one year since the date of sale, during which, our company will repair the fault caused by product quality for free, while, faults caused by incorrect operation, improper maintenance, as well as fire wear and tear are beyond the scope of warranty.
Users need to submit product information to our after-sale service department within the fixed time after purchasing our products, for us to establish customer archives. We have recorded all our products that have been sold, so users need to properly record the products brand and number indicated in certifications, for us to do the follow-up service.
We provide a life-long maintenance service for all products sold by our company
1.Why us?
We provide professional industrial furnace and industrial design as customer order.
2.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every grinder before delivery.
3.Guaranteed?
If products’ quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
4.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.
