Home > Products > coal furnace > pulverized coal cyclone coal furnace boiler
pulverized coal cyclone coal furnace boiler
- 5 Set / Sets per Month
- SHANGHAI
- T/T
Product Details
Condition: | New | Type: | Other, Hot air furnace | Usage: | Heat Treatment Furnace |
Place of Origin: | Hubei, China | Brand Name: | Aojie Technology | Model Number: | WHAJ-PM |
Voltage: | 380V | Power(W): | base on type | Dimension(L*W*H): | base on type |
Weight: | base on type | Certification: | ISO9001 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
pulverized coal cyclone coal furnace boiler
Energy-efficient pulverized coal injection blast furnace
Nation patent(patent No.:ZL03241136.7)
Composition:
Energy efficient pulverized coal injection furnace with rotary dryer (or dryer) is new production line composed by the diffusion injection burner (nation patent), L dual swirl pulverized coal burner (nation patent), and energy-efficient lifting plate for dryer (nation patent).
Application:
The patented technology can be widely used in building materials industry, chemical and fertilizer industry raw material drying and non-ferrous metallurgy, smelting of blister copper, copper powder, dried slime and other industries, especially applicable for of dryer in cement factory, energy-saving technological transformation from oil furnace to coal furnace of Spray Tower in ceramic factory. Compared to artificial and mechanical feeding layer furnace, it can save coal by 30-40%.
2. the furnace apply ordinary bituminous ,lignite and low-grade bituminous with heating capacity>4000 kcal / kg, moisture<10%. It can be regulated from 600 °C to 1500 °C in the furnace, from 600 °C to 1200 °C in the dryer cylinder, from 90 °C to 150 °C for exhaust gas.
Through secondary hot air separator, the dust removal efficiency can reach 96%. Using oxygen combustion technology, the burn off rate of pulverized coal can reach 99% and the slag content is less than 1.5%. The carbon monoxide content in exhaust gas is 0, while the slag content is one-tenth of the other furnace, white.
The Industrial character of energy-efficient diffusion:
1. New pulverized coal injection industrial furnace is automatic control production line. The total investment of it is less than 1/3 of the fluidized bed combustion boiler. Moreover, the construction period is short.
1)Pre-sale services: enthusiasm
Provide you the prophase plan, process flow design and manufacturer equipment according to your special demand.
2)Sale services: servant
Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3)After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to customers.
Service Commitment
The product has a warranty period of one year since the date of sale, during which, our company will repair the fault caused by product quality for free, while, faults caused by incorrect operation, improper maintenance, as well as fire wear and tear are beyond the scope of warranty.
Users need to submit product information to our after-sale service department within the fixed time after purchasing our products, for us to establish customer archives. We have recorded all our products that have been sold, so users need to properly record the products brand and number indicated in certifications, for us to do the follow-up service.
We provide a life-long maintenance service for all products sold by our company
1.Why us?
We provide professional industrial furnace and industrial design as customer order.
2.How is the quality of your products?
Our products are manufactured strictly according to national and international standard, and we take a test on every grinder before delivery.
3.Guaranteed?
If products’ quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
4.How about price?
Yes, we are factory and be able to give you the lowest price than market one, and we have a policy that “ for saving time and absolutely honest business attitude,we quote as low as possible for any customer, and discount can be given according to quantity”.
Contact Us
- Wuhan Aojie Technology Corporation
- Contact nameHelen Lu
- Phone86-27-87461552
- Address3/F, Block 1, HUST Innovation Base, Tangxunhu North Rd. Wuhan East Lake Development Zone Wuhan,Hubei
