1 Ton Walkie Pallet Truck Pallet Jack

FOB Price

US$ 3,000 - 3,800 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	HHIZE	Model Number	CBD
Type	Powered Pallet Truck	Power Souce	AC Motor
Rated Loading Capacity	1000KG	Max. Lifting Height	115mm
Min. Lifting Height	85mm	Fork Length	1150MM
Fork Width	685MM	Overall Dimensions	19807201350MM
Certification	CE,SGS,BV,ISO90001	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

1 ton walkie pallet truck pallet jack

Product description 1 ton walkie pallet truck pallet jack

1. Handle equipped with emergency switch makes the whole vehicle safer.

2. Electricity level display and work hour display

3. Emergency power disconnect switch.

4. Turtle-shaped low speed switch.

5. Stepless control..

6. Low battery protection setting prolongs the battery use time.

7. CANbus technology reduces wiring complexity and increase reliability.

8.Hall element reduces wear components, resulting in increased component life.

9.Solid steel housing could be easily and conveniently opened for maintenance.

10.We can customize according to clients requirements.

Feature
1	Name		1 ton walkie pallet truck pallet jack
2	Model		HZCBD10A-07
3	Power form		Battery
4	Operation Type		Standing
5	Load capacity	Q(Kg)	2000
6	Load center distance	C(mm)	600
7	Hydraulic cylinder		double
8	Color		red yellow blue gray and so on
9	Surface treatment		Paint
10	Gross/net weight	kg	665/660
12	wheel type		polyurethane

Size
1	Rising height	mm	115
2	Falling height	mm	85
3	Overall length	mm	1980
4	Overall width	mm	720
5	Fork size	l/e/s(mm)	115016050
6	Fork overall width	mm	685
7	Overall height	mm	1350
8	Front wheel size	mm	Φ80*70
9	Driving wheel size	mm	φ250*80
10	Balance wheel size	mm	φ125*50
11	passage width,with1000×1200 pallet	Ast(mm)	1100
12	passage width,with800×1200 pallet	Ast(mm)	900
13	Minimum channel width truck turning around	Ast(mm)	2600
14	turning radius	Wa(mm)	1900

Driving
1	Driving motor	Kw	1.2
2	lifting motor	Kw	1.0
3	Battery voltage/capacitance	V/Ah	24/165
4	Battery charged repeatedly		750
5	Battery Weight	Kg	150
6	Charger		24V25A
7	Driving control type		AC
8	Driving motor		Horizontal

Packing and shipping
1	packing method		Packaging as a whole
2	packing		Angle iron + bubble wrap
3	packing size	L/B/H(m)	20.751.5
4	Charger packing size	L/B/H(m m)	470190210
5	How many boxes does each product have		2
6	Number of 20-foot containers	set	22
7	Number of 40-foot containers	set	46

Others
1	Specify product certification	CE,BV,SGS,ISO9001
2	Name of customs declaration	Electric pallet truck
3	FOB	shanghai
4	HS code	8428909090

Accessories 1 ton walkie pallet truck pallet jack

QA&Testing 1 ton walkie pallet truck pallet jack

To ensure security,each 1 ton walkie pallet truck pallet jack will be tested before the sales.

Certifications 1 ton walkie pallet truck pallet jack

Applications 1 ton walkie pallet truck pallet jack

and some other places(Workshop,Warehouse,Airport, Railway Station ,shipyard and so on) where need to carry and shift. Light and flexible 1t mini electric pallet truck

Workshop 1 ton walkie pallet truck pallet jack

Our service 1 ton walkie pallet truck pallet jack

F.A.Q 1 ton walkie pallet truck pallet jack

ton single-faced pallet pallet truck manufacturer

1.Does your factory have discount?

A: Our factory will offer customers 3% vulnerable parts in free .

2.Q:Does your factory accept customizing?

A:Yes,pls send your reguirements to sales3(@).

3.Q: Does your factory accept Neutral Packing and Designed Brand?

A:Yes,we accept.

4:Q:Which is the nearest airport to your factory?

A:Shanghai.We can take you at the airport and provide accommodation.

5.A:Does your factory provide favorable?

Q:Yes,Our factory will offer customers 3% free vulnerable parts .
