1 Ton Electric High Lift Pallet Truck
Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck
Electric Pallet Truck, Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck
One-Stop Material Handling Solutions
Create same and more value than other suppliers at lower price
Production Descirption
1.Electric Lifting,Electric Moving
2.Suitable for Narrow Aisle
3.All Operation Buttons are on the handle,
including " go forward,go backwards,lifting,lowering,Electricity Meter,Hour Meter,etc".
4.Electromegnetic Braking
5.Circuit Design has the function of protecting power failure and excess power.
Product Pictures
Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truck, Electric Pallet Truc
Technical Parameter
Electric Pallet Truck, Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck
| Feature | ||
| Rated Loading Capacity | 1Ton | |
| Load Center | 600mm | |
| Power | Battery | |
| Manipulation | Stand-on Steer Type | |
| Pump Hydrocylinder | Double | |
| Surface Treatment | Baked Paint | |
| Wheel | ||
| Wheel Type | Polyurethane Solid Wheel | |
| Driving wheel Size | φ250mm*80mm | |
| Balance wheel Size | φ125mm*50mm | |
| Load Wheel Size | φ80mm*70mm | |
| Size | ||
| Max Lifting Height | 1200mm | |
| Min Lowered Height | 430mm | |
| Platform Length |
1100mm |
|
| Platform Width |
600mm |
|
| Overall Length | 1980mm | |
| Overall Width | 720mm | |
| Overall Height | 1350mm | |
| Aisle Width(with 1000*1200mm pallet) | 1100mm | |
| Aisle Width(with 800×1200mm pallet) | 800mm | |
| Min Aisle Width for Turning Around | 2600mm | |
| Turning Radius | 1900mm | |
| Performance | ||
| Traveling Speed(with/without load) | 4/6 km/h | |
| Lifting Speed(with/without load) | 40/45 mm/s | |
| Lowering Speed(with/without load) | 50/45 mm/s | |
| Gradient(with/without load) | 5/8 % | |
| Braking Length(with/without load) | 500/350 mm | |
Our Service
1.For end users,we can supply operation video for maintenance, and supply spare parts for free within a year.
2. For distributors, we will build a service center in your country to supply service for you.
Company Introduction
Huize Machine Co.,Ltd Specilizes in Electric Pallet Truck,Electric Stacker, Electric Counter Balance Stacker,Electric Oil Drum Truck, Electric Paper Roll Truck,Electric Crane, Electric Lift Platform and Aerial Order Picker,etc.
We were established in 2006 year, and located in Sancheng Industrial Zone,Jiangyan District,Taizhou City,Jiangsu Province,China. It is about 2.5 hours driving to Shanghai Airport, the transportation is very convenient.
Since our foundation in 2006, we have always insisted on quality is our life,so we operate and inspect every production process strictly to make sure all the products out of our factory 100% qualified, and also every year,our R&D team regularly develop 4-6 new models forklifts in light of market demands
Electric Pallet Truck, Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck
Now we have exported our products to India, Pakistan, Vietam,Singapore, Australia,Saudi Arabia, USA,Canada,etc over 30 countries, and we have very high reputation among all our customers.
Strict Quality Control: 48 hours 100% inpsection of electronic parts test,100% Quality Control before delivery,includin Noisy,Driving,Lifting,and Welding Inspection
Why Choose Huize?
1. Full range products, High-Quality and economic models are both available from Huize,we have resources to help our partners to open the market easily
2. Huize has a whole set of failure predication,repair,maintenance data which will reduce 60% of the dealer's after-sale service cost.
3. Fast. Fast delivery time, Fast service and communication.
Within one hour Huize will respond and within 3 hours we will offer the solution
Less than 15 days standard delivery time for electric products
4. We don't ask more though we do much better! We offer reasonable price level!
5. We are honest and straightforward at work because that is the way we are in our homes, we keep loyal to our partners
