2 Ton China Electric Power Hand Pallet Truck
Product Character
| Character | Function |
|
Front Wheel and Rear Wheel Load Bearing |
make pallet truck driving more steady |
|
Adjusting Driving Wheel with shock-absorbing spring |
enlarge the friction force to avoid slipping |
|
Hardened & Tempered 45# Steel Push Rod |
make push rod keep its shape even if over impact force |
Application
1. FOR FOOD FACTORY
2. FOR TEXTILE FACTORY
3. FOR MEDICAL FACTORY
4. FOR PLASTIC FACTORY
5. FOR CHEMICAL FACTORY
6. FOR ARRICULTURE FACTORY
ALL THE INDUTRIES
Certificate
CE, ISO9001, SGS, BV
Min Order: 1 Sets
Port: Shanghai,Ningbo
Payment: TT, LC
Delivery : 10-15 days after received 30% deposit
Package: Standard Export Package
Technical Parameters
1. |
Feature |
||
1.1 |
Name |
|
High Quality Electric Pallet Truck |
1.2 |
Model |
|
HZCBD20B-10 |
1.3 |
Power |
|
Battery |
1.4 |
Manipulation |
|
Standing Steer Type |
1.5 |
Load Capacity |
|
2000kg |
1.6 |
Load Center |
|
600mm |
1.7 |
Hydro cylinder |
|
Double |
1.8 |
Color |
|
Red, Yellow ,Blue ,Gray |
1.9 |
Surface Treatment |
|
Baked Paint |
2. |
Wheel |
||
2.1 |
Wheel Type |
|
Polyurethane |
2.2 |
Driving wheel No.& Size |
|
1pcs, φ250mm*80mm |
2.3 |
Balance wheel No.& Size |
|
2 pcs, φ125mm*50mm |
2.4 |
Load Wheel No. & Size |
|
4 pcs, Φ80mm*70mm |
3. |
Size |
||
3.1 |
Single Fork Size |
|
1150mm*160mm*50mm |
3.2 |
Fork Overall Width |
|
685mm |
3.3 |
Overall Length |
|
2250mm |
3.4 |
Overall Width |
|
800mm |
3.5 |
Overall height |
|
1500mm |
3.6 |
Lifting Height |
|
115mm |
3.7 |
Lowered Height |
|
85mm |
3.8 |
Aisle Width(with 1000*1200mm pallet) |
|
1100mm |
3.9 |
Aisle Width(with 800×1200mm pallet) |
|
900mm |
3.10 |
Min Aisle Width for Turning Around |
|
2200mm |
3.11 |
Turning Radius |
|
1900mm |
4. |
Performance |
||
4.1 |
Traveling Speed(with/without load) |
|
4/6 km/h |
4.2 |
Lifting Speed(with/without load) |
|
45/50 mm/s |
4.3 |
Lowering Speed(with/without load) |
|
50/45 mm/s |
4.4 |
Gradient(with/without load) |
|
5/8 % |
4.5 |
Braking Length(with/without load) |
|
500/350 mm |
5. |
Driving |
||
5.1 |
Driving Motor |
|
0.75 KW |
5.2 |
Lifting Motor |
|
1.0 KW |
5.3 |
Driving Control Type |
|
Horizontal AC |
6. |
Battery |
||
6.1 |
Battery Voltage/Capacity |
|
24V/210AH |
6.2 |
Recharged Times for Battery |
|
750 times |
6.3 |
Battery Weight |
|
187 kg |
6.4 |
Charger |
|
24V30A |
Photos
Product Accessories
Our Service
1 year warranty
1.For end users,we supply free accessories and maintaining video.
2. For distributors, we will build an after-sale site in your city to supply service for you.
Company Introduction
Huize Machine Co.,Ltd Specilizes in Electric Pallet Truck,Electric Stacker, Electric Counter Balance Stacker,Electric Oil Drum Truck, Electric Paper Roll Truck,Electric Crane, Electric Lift Platform and Aerial Order Picker,etc.
We were established in 2006 year, and located in Sancheng Industrial Zone,Jiangyan District,Taizhou City,Jiangsu Province,China. It is about 2.5 hours driving to Shanghai Airport, the transportation is very convenient.
Since our foundation in 2006, we have always insisted on quality is our life,so we operate and inspect every production process strictly to make sure all the products out of our factory 100% qualified, and also every year,our R&D team regularly develop 4-6 new models forklifts in light of market demands
Electric Pallet Truck, Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck , Electric Pallet Truck
Now we have exported our products to India, Pakistan, Vietam,Singapore, Australia,Saudi Arabia, USA,Canada,etc over 30 countries, and we have very high reputation among all our customers.
Strict Quality Control: 48 hours 100% inpsection of electronic parts test,100% Quality Control before delivery,includin Noisy,Driving,Lifting,and Welding Inspection
Why Choose Huize?
1. Full range products, High-Quality and economic models are both available from Huize,we have resources to help our partners to open the market easily
2. Huize has a whole set of failure predication,repair,maintenance data which will reduce 60% of the dealer's after-sale service cost.
3. Fast. Fast delivery time, Fast service and communication.
Within one hour Huize will respond and within 3 hours we will offer the solution
Less than 15 days standard delivery time for electric products
4. We don't ask more though we do much better! We offer reasonable price level!
5. We are honest and straightforward at work because that is the way we are in our homes, we keep loyal to our partners
