Capacity 500kg,6m mobile hydraulic scissor lift
Product description
capacity 500kg,6m mobile hydraulic scissor lift
1 |
Characteristic |
||
1.1 |
Name |
|
capacity 500kg,6m mobile hydraulic scissor lift |
1.2 |
Model |
|
SJY -500-6 |
1.3 |
Operator Type |
|
Push by hand |
1.4 |
Load capacity |
Kg |
500 |
1.5 |
Power voltage |
|
380V50HZ( three phase) |
1.6 |
Lifting motor |
KW |
1.5 |
1.7 |
Scissors boom rectangular tube |
mm |
100*40 |
1.8 |
Scissors boom |
Layer |
4 |
1.9 |
Table-board |
|
Diamond plate |
1.10 |
Color |
|
Green , red , blue and so on |
2 |
Size |
||
2.1 |
Lifting height |
mm |
6000 |
2.2 |
Operating height |
mm |
7700 |
2.3 |
Guardrail height |
mm |
1000 |
2.4 |
Chassis size |
mm |
1950 (length)*1000 (width) |
2.5 |
Support leg length |
mm |
600 |
2.6 |
Overall length |
mm |
2000 |
2.7 |
Overall width |
mm |
1120 |
2.8 |
Overall height |
mm |
1150 |
2.9 |
Channel width |
Ast(mm) |
1000 |
2.10 |
Minimum channel width truck turning around |
Ast(mm) |
2050 |
5 |
Performance |
||
5.1 |
Lifting speed (loaded/unloaded) |
mm/s |
60/80 |
5.2 |
Falling speed (loaded/unloaded) |
mm/s |
85/81 |
3.5m CE Electric power walkie rider forklif
Certifications capacity 500kg,6m mobile hydraulic scissor lift
1ton 3.5m CE Electric power walkie rider forklift
Applications1 capacity 500kg,6m mobile hydraulic scissor lift
Station,Port,Warehouse,Bridge,Equipment maintentance , the renovation of houses and so on
E mobile scis
After-sales service capacity 500kg,6m mobile hydraulic scissor lift
1.End users:We can provide video to tell you how to maintain and repair;
Provide accessories for free in one year;
One year later ,provide these accessories at cost and charge
express fee.
2.Retailer:To provide perfect after-
sales service ,our company send someone to retailer’s country.
F.A.Q capacity 500kg,6m mobile hydraulic scissor lift
1.Q:Does your factory have favorable?
A: Our factory will offer customers 3% vulnerable parts in free .
2.Q:Does your factory accept customizing?
A:Yes,pls send your reguirements to sales3(@).
3.Q: Does your factory accept Neutral Packing and Designed Brand?
A:Yes,we accept.
4:Q:Which is the nearest airport to your factory?
A:Shanghai.We can take you at the airport and provide accommodation.
5.A:Does your factory provide favorable?
Q:Yes,Our factory will offer customers 3% free vulnerable parts .
