EPS1050/1050 thermoforming machine integrates vacuum forming with mold forming. It can form almost all thermoforming plastic sheets. It adopts PLC control system, panel and digtial power control adjustment. This fully automatic forming equipment is for thermoforming plastic sheets integrating feeding and heating with forming, cooling, mold ejecting and cutting. This machine features performance and convenient operation.
Applications:
It is suitable for thermoforming PS, HIPS, PVC, PET, PP and flocking sheets to produce various infills that used in cooling tower.
Main technical parameters:
1) Length of forming: 760 - 1,050mm
2) Width of forming: 500 - 1,050mm
3) Height of forming: ≤165mm
4) Production speed: 180 - 1,200 cycles/h
5) Power of oven: 117kw
6) Power of vacuum pump motor: 3kw
7) Pump speed of vacuum: 100cbm/h
8) Power of air compressor: 15kw
9) Air displacement of air compressor: 0.8cbm/min
10) Voltage: 380/220V 50Hz
11) Forming pressure: 20T
12) Overall dimensions: 7,560 x 1,780 x 2,600mm
13) Weight: 6,500kg
