2015 Hot Sale dual 10 inch 2-way passive line array speakers for outdoor concert meeting party
line array; speaker box line array system; professional speaker system
pro line array speaker mini line array speaker line array speaker design
Model: line array speaker, L210
| Speaker Type | DUAL 10” 2-way Passive Speaker |
| Frequency Response | 45-18k Hz |
| Sensitivity (1W/1m) | 99dB/m |
| Nominal Impedance | 8Ωx2 16Ωx2 |
| Rated Power | 450W |
| Peak Power | 1650W |
| Nominal Coverage | 90°x 12°(HxV) |
| Crossover | NC |
| Low / Mid Woofer | 10” 65mm VC x2 |
| HF Driver | 44mm VC 1” throat x 2.8Ω |
| Low / Mid Woofer | 250W x2, 8Ω(16Ω) |
| Hi Power | 80W x2, 8Ω |
| SPL | 34dB (140dB peak) |
| Recommended AMP | 600W ~ 1000W |
| Input Connector | 2xNL4R, Spekon, Link+1-1 |
| Cabinet Construction | 15mm layer plywood |
| Dimension (WxHxD) | 900 x 365 x 465 mm |
| Weight | 35KGS |
Picture of L210 line array speaker:
L-SERIES linear array speaker cabinet is trapezoidal structure, a unique way of hanging high density arrays can be used for placement, especially for a centralized system, pointing particularly strong, especially in the low frequency directivity there will be very greatly improved, greatly improved the sound field uniformity and clarity of the indicators.
L-SERIES linear array of speakers, from different angles since the abduction angle, far above components provide the required energy density listener States, while the lower seat assembly to close off the audience to achieve uniform coverage range, excluding the traditional flat Centralized horn sound field produced by an array of speakers interference.
L-SERIES linear array speaker components implemented in the whole band good acoustic coupling, so that the loss of interference generated by the speaker unit to minimize response to a combination of suspension from dual-component and a collection of far, L -SERIES line array to perform works to provide a more efficient and high-quality sound system, formed from near and far coverage solutions. L-SERIES linear array speaker cabinet is trapezoidal structure, a unique way of hanging high density arrays can be used for placement, especially for a centralized system, pointing particularly strong, especially in the low frequency directivity there will be very greatly improved, greatly improved the sound field uniformity and clarity of the indicators.
