hydraulic press for rubber vulcanization molding press/vulcanizer
Rubber Belt Joint Transfer Molding Machine/Rubber Transfer Molding Press/Frame type Rubber Transfer Vulcanizing Machine :
The machine feaure conpact structure,high automation,the rubber transfer molding machine is widely used to produce rubber products with metal insert,big cross section,complex shape,thick wall.
Item |
JC-XZB-D350 |
Clamping force (KN) |
350 |
Max System Pressure (MPa) |
20 |
Clamping stroke (mm) |
350 |
Rapid clamping speed (mm/s) |
≥30 |
Heating platen size (mm×mm) |
300×350 |
Heating Plate Spacing (mm) |
30~350 |
Max temperature (°C) |
250 |
Material Cylinder Spec(Dia-mm×Hei-mm) |
Φ40×165 |
Injection Stroke (mm) |
270 |
Injection Pressure (MPa) |
80 |
Motor Power (kW) |
3 |
Heating Power (kW) |
4.4 |
External Dimension(L×W×H)mm |
1000×1500×2345 |
Weight (kg) |
1650 |
Oil Tank Capacity (L) |
200 |
