pp pe Pvc Eva Masterbatch Machine Production Line,plant
US$ 60,000 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Granulating Production Line
Capacity:
400-600 KG/H
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plastic Caco3 Masterbatch Granule Extruder MachineUS$ 20,000 - 70,000MOQ: 1 Set -
Tup Extruder Pellet Machine ManufacturerUS$ 20,000 - 70,000MOQ: 1 Set
-
Sulphur Granules Extruder Machine for pp pe Eva Plastic Filler CompoundUS$ 20,000 - 70,000MOQ: 1 Set
-
Single Screw Granulator Plastics Extruder for SaleUS$ 20,000 - 70,000MOQ: 1 Set
-
Pvc Compound Filler Masterbatch Pelletizing/granules Manchine and Production LineUS$ 20,000 - 70,000MOQ: 1 Set
Condition
New
Type
Granulating Production Line
Capacity
400-600 KG/H
Place of Origin
Jiangsu, China
Brand Name
MIXER
Model Number
MD-130/75L
Material
Other, EVA/TPR/PP/PE
Screw Design
Single
Voltage
380V,220V,480V
Power
200KW
Dimension(L*W*H)
1500x220x320 cm
Weight
17000 KG
Certification
CE
Warranty
1 Year after shipment
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
pvc compounding plant/compounding masterbatch plastic extruder machine/pe compound pellets
The high speed compound extruder production line is ideal for making EVA granules,master batches & Compounding PP/PE,PVC TPR, low smoke zero halogen (LSZH) cable materials, ABS, LDPE, HLDPE, etc. You can use the master batches & Compounding for making: Shopping & Carrier bags, Woven Sack Multilayer Films, Water Tanks PE & PVC Cables, PVC Shoes, Cing Film, Anti Block P.P etc.
The production line combines materials mixing, conveying, feeding, extrusion granulation, water circulation cooling and air cooling sending as a whole line, automated continuous operation, the high effective production. Frequency converter used to control the rate of granulation to meet the speed of material requirements and savings power function.
Compact structure, occupies little space and can be installed flat.
Production sub-loop temperature control process, dispersion kneader, feeder, extrusion machine has its own heating and cooling system, control their temperature, according to process requirements. Feeding machine is of double screw propeller extrusion feeder, with the feature of strong material feeding, especially suitable for extrusion and granulation of mixed compound directly from kneader.
Barrel screw use 38CrMoAlA quality alloy steel, nit riding treatment, high hardness, wear resistance to corrosion.
Machine head adopt manually net changing organization, easy to operate.
Electronic control system uses advanced PLC control technology, and two inverters form, then mixing, feed, extrusion, palletizing and other multi-process machine according to the requirements of high accuracy, wide variable speed. And the line has the whole chain of machine technology, sound and light alarm functions; improve the reliability and safe operation. Granules palletized from this line are with the features of beautiful appearance, fine texture, well distributed.
Technical spefictionation:
Model | MD-100/35L | MD-120/55L | MD-130/75L | MD-165/110L | MD-200/110L |
Extrusion capacity(KG/H) | 150-200 | 200-300 | 400-600 | 500-800 | 600-1000 |
Screw Diameter | 100mm | 120mm | 130mm | 165mm | 200mm |
Screw L/D ration | 12,16,20 | 12,16,20 | 12,16,20 | 12,16,20 | 12,16,20 |
Extruder motor (KW) | 37 | 45 | 55 | 75/90 | 110/160 |
Temperature control stages | 4 | 4 | 4 | 4 | 4 |
Feeding power(KW) | 5.5 | 7.5 | 7.5 | 7.5/11 | 11 |
Die cutting power(KW) | 2.2 | 2.2 | 2.2 | 2.2 | 2.2 |
Cooling system power(KW) | 3 | 3 | 5.5 | 7.5 | 11 |
Vibrator sieve diameter (mm) | 2.5/3 | 2.5/3 | 2.5/3 | 2.5/3 | 2.5/3 |
Spin drier motor (KW) | 7.5 | 7.5 | 7.5 | 7.5 | 11 |
Hopper | 1000L | 1000L | 1000L | 1500L | 2000L |
Kneader model | X(S)N-35L | X(S)N-55L | X(S)N-75L | X(S)N-110L | X(S)N-110L |
