Specifications
7W/9W/12W Led Cob down Light
1.Power:7W,9W,12W is options
2.Size:φ85XH58mm
3.Mounting hole:Φ75
4. Input voltage:AC85-265v
5.CCT:3000K/4000K/5000K
6.CRI:>85
7.Beam angle:12D/15D/24D/38D/60D
8.Light Source:CREE/CITIZEN
9.Dimming mode:SCR/PWM
CE&RoHs
Best Low Price,LED Downlight 7W/9W/12W Led Cob ceiling Light
CREE 7W/9W/12W cob led down light kit specs;
Model number |
CS0301-A2-7W |
CS0301-A2-9W |
CS0301-A2-12W |
|
LED |
Origin |
CREE COB(1pcs) |
CREE COB(1pcs) |
CREE COB(1pcs) |
|
Lumens |
CREE1507 7W |
CREE1507 9W |
CREE1507 12W |
|
Beam Angle |
12D/15D/24D/38D/60D |
12D/15D/24D/38D/60D |
12D/15D/24D/38D/60D |
Color temperature |
3000K/4000K/5000K |
3000K/4000K/5000K |
3000K/4000K/5000K |
|
Power consumption |
7W |
9W |
12W |
|
PFC |
0.9 |
0.9 |
0.9 |
|
Input voltage |
100-240V AC |
100-240V AC |
100-240V AC |
|
Working temperature |
-15~+40 |
-15~+40 |
-15~+40 |
|
CRI |
>85 |
>85 |
>85 |
|
Dimension |
φ85XH58mm |
φ85XH58mm |
φ85XH58mm |
|
Mounting hole |
Φ75 |
Φ75 |
75 |
|
COB 7W /9W/12W cob led down light
Lumens Decline |
3% in the first 1000hours |
Feature |
Environmentally Friendly, no UV & IR Radiation Electricity Bills is almost save up to 75 - 80% A popular and Nice stylish LED Item
|
Application |
Step lighting, light boxes Cabinet and under counter lighting
|
Installation
1. Make a Hole, MAKE SURE the hole drilling size is correct
2. Connect the Power Wire with the Product Wire
3. Push Spring and fix the clip
4.Put the Lamp into the Hole
1. Payment: 1>Paypal is very welcome.2>T/T 30% deposits, 70%balance to be paid before deliver
2. Production Lead Time for 100~500pcs: 10~15days
3. Sample can be delivered in 3-7days
4.Shipping freight are quoted under your requests
5.Shipping port: Shenzhen, Mainland China
6.Discounts are offered based on order quantities;
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English
3.OEM&ODM, any your customized lightings we can help you to design and put into product.
4.Distributoership are offered for your unique design and some our current models
5.Protection of your sales area, ideas of design and all your private information
Welcome to contact us for more style and sizes with the datas and better price!
