200KW Volvo Silent Diesel Generator Set
- Fuzhou Port
- T/T Credit Card PayPal
You May Like
-
Sweden 200KW/250KVA Volvo Silent Diesel Generator Set TAD734GE
-
Global Warranty! Sweden 200KW/250KVA Volvo Silent Diesel Generator Set TAD734GE
-
Volvo Diesel Generator Set
-
180KVA 200KVA 250KVA 312KVA Volvo Diesel Generator For Home Use
-
Low Fuel Consumption Volvo Diesel Generator Engine TAD1643GE,500kw/625kva
-
85kva - 600kva Volvo Diesel Generator, Volvo Penta Genset OEM
Product Details
| Place of Origin | Fujian, China | Brand Name | Volvo | |
| Model Number | SMV, Saint Meilan | Output Type | AC Three Phase | |
| Speed | 1500RPM/1800RPM | Frequency | 50/60Hz | |
| Rated Power | 10kva--1250kva | Rated Voltage | 110V/240V, 220V/380V, 230V/400V, 240V/415V | |
| Rated Current | 5-2000A |
Product Description
Specifications
Volvo Generator Set1 Stamford alternator
2 Noise 70 db
3.CE&ISO,SONCAP,COI,SGS
4.Silent,mobile available
200KW Volvo Silent Diesel Generator Set
| Frequency 50Hz | VOLVO PENTA | Dimension (L*W*H)(mm*mm*mm) | ||
Model | Standby | Prime | Open Type | Soundproof | |
SMV94 | 94/75 | 85/68 | TD520GE | 2080*680*1450 | 2760*1140*1830 |
SMV109 | 109/87 | 100/80 | TAD531GE | 2080*750*1450 | 2760*1140*1830 |
SMV142 | 142/114 | 130/104 | TAD532GE | 2280*920*1550 | 3230*1170*1800 |
SMV165 | 165/132 | 150/120 | TAD731GE | 2400*870*1450 | 3230*1170*1800 |
SMV206 | 206/165 | 188/150 | TAD732GE | 2600*1050*1770 | 3590*1250*2050 |
SMV220 | 220/176 | 200/160 | TAD733GE | 2600*1050*1770 | 3590*1250*2050 |
SMV275 | 275/220 | 250/200 | TAD734GE | 2600*1120*1670 | 3590*1250*2050 |
Generating Set Data | ||
Generating Set Model | SMLV-260 | |
Generating Set Power | Prime power(50Hz) | Standby power(50Hz) |
260KW/325KVA | 286KW/358KVA | |
Rated Voltage / Frequency | 400/230V, 50Hz, 3-phase, 1500rpm | |
Dimension (mm) | 3150*1100*1600 | |
Engine Data | ||
Engine Model | VOLVO TAD941GE | |
Air Intake System | Turbo Air to air intercooler | |
Fuel System | Directly Injection Fuel System, Bosch Pump | |
Cylinder Arrangement | 6 in line | |
Max. Standby Power at Rated RPM | 308KW/419HP (with fan) | |
Bore×Stroke | 120*138(mm) | |
Displacement | 9.36L | |
Compression Ratio | 17.4 | |
Rated Speed | 1500r/min | |
Governor | EMS2 | |
Exhaust Gas Flow | 52.2m3/min | |
Exhaust Temperature | 519°C | |
Max Back Pressure | 10kPa | |
Alternator Data |
| |
Alternator manufacturer | Stamford | |
Connecting Type | 3 Phase and 4 Wires, “Y” type connecting | |
Voltage Regulation, Steady State | ≤±1% | |
Alternator Capacity | 350KVA | |
Alternator Efficiencies | 93.5% | |
Air Cooling Flow | 0.8m³/s | |
Generating Set Data |
| |
Voltage Regulation | ≥±5% | |
Voltage Regulation, Stead State | ≤±1% | |
Sudden Voltage Warp (100% Sudden Reduce) | ≤+20% | |
Sudden Voltage Warp (Sudden Increase) | ≤-15% | |
Voltage Stable Time (100% Sudden Reduce) | ≤4S | |
Voltage Stable Time (Sudden Increase) | ≤4S | |
Noise Level | 114dB | |
