Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > P14-6S FG Wilson 13kVA 404D-22G Diesel Generator

P14-6S FG Wilson 13kVA 404D-22G Diesel Generator

Name: P14-6S FG Wilson 13kVA 404D-22G Diesel Generator
Brand: FG Wilson or OEM
SKU: 129249383
Availability: InStock

P14-6S FG Wilson 13kVA 404D-22G Diesel Generator thumbnail-1

P14-6S FG Wilson 13kVA 404D-22G Diesel Generator thumbnail-2

P14-6S FG Wilson 13kVA 404D-22G Diesel Generator photo-1

P14-6S FG Wilson 13kVA 404D-22G Diesel Generator photo-2

US$ 3,500 - 4,800 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

London, United Kingdom

Brand Name:

FG Wilson or OEM

Model Number:

P14-6S, P14-6S

Contact Supplier Request Quote Chat Now

Fujian Saint Meilan Motor Wiring Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin London, United Kingdom

Brand Name FG Wilson or OEM

Model Number P14-6S, P14-6S

Output Type AC Three Phase

Speed 1500/1800RPM

Frequency 50Hz/60HZ

Rated Power 5kva--1000kva

Rated Voltage 220V/380V, 230V/400V, 240V/415V

Rated Current 5-200A

Specifications

Power Generators
1.Automatic transfer ,60Hz and 50Hz
2.OEM parts service
3.Two weeks Delivery
4.CE and TUV approved

P14-6S FG Wilson 13kVA 404D-22G Diesel Generator

Diesel Generator Set Name	kVA @ 50 Hz	kW @ 50 Hz	kVA @ 60 Hz	kW @ 60 Hz
P 7.5-4S	6.8 / 7.5	6.8 / 7.5	8.0 / 8.8	8.0 / 8.8
P 9.5-4	8.5 / 9.5	6.8 / 7.6	10.0 / 11.0	8.0 / 8.8
P11-6S	10.0 / 11.0	10.0 / 11.0	12.0 / 12.0	12.0 / 13.0
P13.5-6	12.5 / 13.5	10.0 / 10.8	15.0 / 16.5	12.0 / 13.2
P14-6S	13.0 / 14.0	13.0 / 14.0	15.5 / 17.0	15.5 / 17.0
P16.5-6S	15.0 / 16.5	15.0 / 16.5	17.6 / 19.4	17.6 / 19.4
P18-6	16.5 / 18.0	13.2 / 14.4	20.0 / 22.0	16.0 / 17.6
P22-6	20.0 / 22.0	16.0 / 17.6	22.5 / 25.0	18.0 / 20.0

Defeng Genset Model	SMLP14-6S
	Prime	Standby
Genset Power (kW/kVA)	16/20	17.6/22
Engine Model	404D-22G
Engine Power (kW)	22	24.2
Engine Make	Perkins
Engine Cooling Method	Water Cool
Speed Governing System	Electronic
Starting Method	12V Electric Start
Engine Filter System	Dry-type air cleaner, fuel filter, oil filter
Fuel System	Direct Injection
Engine Displacement (L)	2.2
Cylinder Bore×Stroke(mm)	84×100
Fuel Consumption 100% Load (g/KW.h)	5.3	5.8
Engine Oil ConsumptionL/h	0.05
Air-flow (m³/min)	85
Gas Consumption (m³/min)	1.61
Exhaust Smoke Level (m³/min	4.80
Exhaust Temperature ()	450
Oil Capacity (L	10.6
Coolant Capacity (L	14.8
Generator Make	LEROYSOMER LSA42.5 S5
Generator Excitation Type	Brushless Self-exciting
Short Circuit Protection	MCCB Airbreak Switch
Rated Voltage/frequency/Power Factor	400V/230V,50Hz, 0.8 delay,3-phase, 4-wire
Steady Frequency Change	Better than 1%
No Load Voltage Adjusting Range	≥95%105%
Steady Voltage Adjusting Rate	Better than ±1%
Insulation Degree/ Protection Levels	Class H /IP22
Tel. Influence coefficient/Harmonic Wave Factor	THF2%
Accessories	Starting battery, connecting lines, fume exhaust curved pipe, damping corrugating tube, flange, muffler, chassis shock absorber
Dimensions(mm)	1330×556×1270
Genset Weight (kg)	460
Genset Noise dB(A)	98
Advised Machine Room Dimension(mm)	6000×4000×3000

SML Twin Cylinder 10kw Power Solution

Diesel

SMLDG10LS 10kw Silent 3000/3600rpm Portable

SMLDG10L 10kw Open 3000/3600rpm Portable

SMLW10S 10kw Silent 1500/1800rpm Heavy Duty

SMLW10 10kw Open 1500/1800rpm Heavy Duty

Diesel SMLW10 series --Weichai,Yangdong,Isuzu,FG Wilson

Diesel Generator Outputs from 3kva to 2500kva, 50hz and 60hz.

Our Services

1. We provide one year warranty for all of our products count from the datd of B/L. If the machine break during he warranty period due to quality or assembling problem, we provide free spare parts to our customer for reparing. After expiration, we provide cost spare parts service.

2. We provide free technical consultant if you have any question about the usage of our products.

3. We can make OEM as per request of our customer, such as customer brand, label, package, special model design, color, etc.

FAQ

1. Q: What's the MOQ for this model ?

A: The MOQ for this products is 20 units. But for sample order, we also accept 1-2 units.

2. Q: What's the delivery time ?

A: For sample order, the delivery time usually within 1-2 weeks, for container order, usually cost 1 month. Please check with sales for exact information.

3. Q: How about the production capacity ?

A: FYI, the current production capacity for our gasoline engine products is 1,000units/month.

We will reply within 1-12 hours. Thank you for your time!
