Specifications
1.Digital2.warranty
3.CE,ISO,SONCAP
4.Easy operating
Isuze Generator 8 - 23 kW Lowest Price Saint Meilan
ISUZU developed Japan's first diesel engine in 1934, and marked cumulative production of over 16 million diesel engines in 2003. Cumulative OEM sales stand at over 3 million units, while in Japan alone Isuzu holds a share greater than 50% of the non-captive OEM market. The reliability and durability have been proven in applications ranging from cooler power sources for refrigerated trucks to construction machinery, agricultural tractors and boats. Isuzu is also a leader in customer support-from installation studies to worldwide field service operations-and in environmentally friendly diesel engine technologies.
It has the following feature:
1. Reliability: crankshaft is forged by alloy steel,which can make the use-life 3 time than common cast-iron crankshaft
2.Economical:Cylinder-bore diameter is 93 mm,and the displacement is small.fuel consumption can reach 213g/kw.h
3.Environmental: Crankshaft pulleys uncounterbalance would less than 30g.cm,and assured the compression ratio of the engine invariably and work stably
4.Low Noise : ≤86dB(A) at 1 meter away from the engine.≤69dB(A) at 7 meter
Denyo copy style,Japanese technology!
SPECIFICATIONS OF ENGINE
Engine Brand |
ISUZU |
Engine Model |
4JB1T |
Governor/Class |
Mechanical/Electrical(select) |
Cylinder NO. |
4 |
Engine build |
Line |
Fuel spray pattern |
Direct injection |
start-up method |
12V, electric |
Aspiration |
Turbocharged |
Cooling mode |
Radiator cooled (enclose water) |
Bore and stroke |
93×102 mm |
Compression ratio |
18.2:1 |
Displacement |
2.771 L |
Engine Prime Power at 1500rpm |
30KWm |
Engine Standby Power at 1500rpm |
33KWm |
Battery capacity |
80A/hr |
Starting/Min temperature |
select |
Lubrication oil capacity |
4.5L |
Coolant capacity – radiator and engine (40°C) |
10L |
Exhaust temp – full load prime |
<600°C |
Exhaust gas flow – full load prime |
12000m3/h |
Exhaust gas back pressure max |
25mmHg |
Air flow – radiator (40°Cambient) |
2.7 m3/s |
Pusher fan head (duct allowance) 40°C |
/ |
Air intake – engine– full load prime |
12600m3/h |
Standard Air intake temp |
25°C |
Fuel type |
#0 Diesel (Natural temperature) |
Filter system |
Adopt whole changeable lubricating oil, fuel filter and air filter |
Exhaust system |
Adopt industrial high efficiency silencer and flexible bellows |
Engine derating – altitude |
Above the sea-level 1000m high, a fall of 4% from a rise of 300m. |
Engine derating – temperature |
Above the ambient temperature 40°Chigh, a fall of 2% from a rise of 11%. |
MCCB
3. FAQ
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T as deposit in advance, 70% balance receipt of the copy of B/L or before shipment.
Q: What is your lead time?
A: About 25 days after receipt the deposit or original irrevocable L/C.
Q: What certifiicate do you have?
A: We have CE, ISO. And we can apply for specific certificate for different country such as COI for Iran, SASO for Saudi Arabia, etc.
Thank you !
